TOP VENTING PARTS
For Models:GBD307PRQ00, GBD307PRB00, GBD307PRS00, GBD307PRT00
(Designer White)
(Black) (S.Steel) (Biscuit)
Illus.
No.
Part
No.
DESCRIPTION
Illus.
No.
Part
No.
DESCRIPTION
Illus.
No.
Part
No.
DESCRIPTION
1
4451759
Assembly,
7
8302390
Bracket, Support
15
9759135
Back, Control
2
4455178
Elbow, Vent Top
(Air Stop)
4449809
Screw
3
4455177
Elbow, Vent Btm
11
4449868
Block, Terminal
16
4450551
Cover, Top Rear
4
Blower
3400080
Screw
4449809
Screw
6610168
45MM Lower Oven
13
8303497
Vent,
17
4448664
Clamp
4457289
65MM Upper Oven
(Control Panel)
4449809
Screw
4455191
Bracket
4450038
Screw
112432
Nut
5
4451758
Foam, Block
14
Side, Control Top
18
4452367
Cover, Top Front
6
8300642
Transformer,
4451597
Right
4449809
Screw
Control
4451598
Left
19
9759243
Thermostat, Oven
4449809
4449154
Screw
Screw
20
8302143
Suppressor
8186315
F O R O R D E R I N G I N F O R M A T I O N R E F E R T O P A R T S P R I C E L I S T
