Parts list – Chicago Electric 97677 User Manual
Page 13
Page 13
SKU 97677
For technical questions, please call 1-800-444-3353.
Part #
Description
Qty.
Part #
Description
Qty.
1
Decorative Cover
1
45
Caster (55mm)
2
2A
Screw (ST4.2x16-F)
24
46
Base
1
3
Upper Cover Pressing Plate
2
47
Intake Bracket
1
4A
Screw (ST3.5x16-F)
3
48
Intake Seal
1
5A
Screw (ST2.9x8-F)
4
49
Intake Port
1
6
Tool Interface
1
50
Suction Hose
1
7
Tool Interface
1
51
Pressing Cover Sealing Bar
2
8
Upper Cover Interface Plate
1
52
Sealing Washer B
2
9
Upper Cover
1
53
Filter Cover
1
10
Connecting Cap (#3)
1
54
Cartridge Filter
1
11
Power Cord/Plug
1
55
Pressing Plate
1
12
Cord Sleeve
1
56A
Screw w/Washer (ST4.2x20)
2
13A
Screw (ST4.2x13-F)
4
57
Inner Pressing Plate
2
14
Middle Cover
1
58
Outward Pressing Plate
2
15
Exhaust Cover Gasket
2
59
Left Latch
1
16
Middle Motor Gasket
1
60
Latch Cover
2
17
Handle Sleeve
1
61
Pressing Plate
2
18
Upper Handle
1
62
Upper Cover
1
19
Handle Pipe
2
63
Safety Float
1
20
Lower Handle
2
64
Sealing Washer A
1
21A
Flange Screw (M4x60)
2
65
Sealing Cover
1
22
Drain Clip
1
66
Motor bottom Sealing Loop
1
23
Cord Clip
2
67
Air Flow Adjusting Knob
1
24
Outward Pressing Plate
2
68
Air Flow Regulator
1
25
Inner Pressing Plate
2
69
Motor
1
26A
Flange Screw (M4x30)
1
70A
Screw (ST2.9x8-F)
1
27
Drain Cover
1
71
Electrical Wiring Pressing Plate
1
28
Drain Cover Strap
1
72A
Safety Cover
1
29
Drain Hose
1
30
Drain Spring Clip
1
74
Silencing Filter
1
31
Drain Tie-In
1
75A
Screw (ST2.5x13-C)
3
32
Drain Washer
4
76A
Exhaust Cover
1
33
Drain Nut
1
77A
Screw (St2.5x9.5-C)
2
34
Right Latch
1
78
Switch
1
35
Tank
1
79
O-Ring (15x2.65g)
1
36
Wheel Cover
2
80A
Switch Knob
1
37A
Screw (ST2.9x8)
4
81
Handle
1
38
Pin “A” (3.2x20)
2
82
Telescopic Suction Tube
1
39
Washer (#10)
2
83
Wet & Dry Brush
1
40
Wheel
2
84
Filter Cage
1
41
Axle Bracket
2
85
Foam Filter
1
42
Axle
1
86
Crevice Nozzle
1
43A
Screw w/Washer (ST2.9x13-F)
1
87
Furniture Brush
1
44
Grounding Chain
1
88
Dust Bag
1
PARTS LIST
REV 10c
