Mini Fuse Usage
71
Fuel Heater/Flex
Fuel Sensor
72
Body Control
Module 6
73
Lighter/Data Link
Connection
75 V6 Fuel Injectors
76 Spare
77
Oxygen Sensor
2 (Pre)
78
Engine Control
Module Powertrain
79
Even Ignition/
Injectors
J‐Case Fuse Usage
1 ABS Motor
2 ABS Module
41 Spare
42 Trailer Wiring
43 Fan High
44 Starter Solenoid
45
Engine Control
Module/Powertrain
46 Spare
47 Fan Lo
74 Front Blower
Relay Usage
15 Run/Crank
37 Spare
38 Fuel Pump
39 Crank
40
Air Conditioning
Compressor
48 Fan High
49 Powertrain
50 Spare
57 Fan Low
60 Fan Control
