Controls and Features
FULL BYPASS - Each channel of the Curve Bender may be fully bypassed by use of these pushbuttons.
HIGH PASS/LOW PASS - Although the original Curve Bender and TG12345 console did not
frequencies, it is an important fact that new circuitry was not invented to add this feature. Simply
Frequencies are:
High Pass - 20, 30, 40, 50, 60, 80, 100, 160, 200, 320 Hz at a gentle slope.
Low Pass - 30, 20, 18, 14, 10, 8.1, 5, 3, 2 kHz at a gentle slope.
OUTPUT GAIN - In the TG tradition each channel has a gain switch with +/-10db adjustment
in 1db steps for adjusting unity gain through the unit as you apply equalization. The switch is a
hand-wired gold contact switch for audiophile quality.
