sPeCIfICaTIoNs
Performance specifications
– Rated Pull 10,000 lbs (4536 kg)
– Gear Reduction Ratio 216:1
– Motor Series Wound Motor 3 .6 HP/2 .7 kW (12V DC)
– Duty Cycle Intermittent Use Only
– Drum Size 2 .48” (D) x 8 .84” (L) [63 mm (D) x 224 .5 mm (L)]
– Cable 3/8” (D) x 85’ (L) [9 .2 mm (D) x 26 m (L)]
– Gross Weight 92 .5 lbs . (42 kg)
– Net Weight 85 lbs . (38 .6 kg)
– Height 10 .5 inches (26 .7 cm)
– Width 5 .6 inches (14 .2 cm)
– Length 21 .9 inches (55 .5 cm)
– Bolt Pattern 10” x 4 .5” (25 .4 cm x 11 .43 cm)
Line Speed and Motor Current (First Layer)
Line Pull
LB 0 2000 4000 6000 8000 10000
KG 0 907 1814 2722 3629 4536
Line Speed (12V DC)
FPM 15 .7 9 .8 7 .2 5 .9 4 .9 3 .9
MPM 4 .8 3 .0 2 .2 1 .8 1 .5 1 .2
Max Current A 115 175 220 280 320 400
Run Time* Minutes 1 1 1 1 1 1
Cooling Time** Minutes 5 5 5 5 5 5
Line Pull and Cable Capacity Per Layer
Line of Cable 1 2 3 4
Rated Line Pull
LB 10000 8000 6600 5600
KG 4536 3629 2994 2540
Cable Capacity
FT 18 39 .4 64 85
M 5 .5 12 19 .5 26
– Use double line and snatch block for pulling loads over 8,000 lbs . (3628 .7 kg) .
* If the motor becomes uncomfortably hot to the touch, stop winching immediately and let it cool down for 5 minutes . Do not
pull for more than one minute at or near the rated load .
** Electric winches are designed and made for intermittent use and should not be used in constant duty applications .
