Champion Power Equipment 92221 - Manual (Page 27)

REV 92221-20130425
24
92221 ENGLISH Engine Parts List
# Part Number Description Qty
1 1.5789.0608 Flange Bolt M6×8 5
2 22.061100.00.02 Recoil Starter Cover 1
3 21.061005.00 Recoil Starter Spring 1
4 2.10.003 Rope (ш5Ч1550) 1
5 21.061001.01 Recoil Starter Reel 1
6 45.060003.00 Spring,Ratchet 2
7 45.060002.00 Starter Ratchet (Iron) 2
8 45.060009.00 Spring,Ratchet Guide 1
9 45.060007.00 Ratchet Guide 1
10 45.060008.00 Screw, Ratchet Guide 1
11 1.5789.0612 Flange Bolt M6×12 10
12 24.080100.01.48 Fan Cover 1
13 2.05.002 Clamp (ш9.5Ч5) 1
14 21.061300.00 Recoil Handle 1
15 2.02.006 Nut (M14×1.5) 1
16 21.060001.01 Pulley, Starter 1
17 23.080001.00 Cooling Fan 1
18 24.120100.02 Flywheel (EPA) 1
19 2.11.001 Oil Seal (ш25Чш41.3Ч6) 2
20 2.03.020.1 Washer (ш6.2Чш15Ч0.5) 1
21 21.110100.00 Gear, Governor 1
22 21.110013.00 Shaft, Governor Gear 1
23 21.110011.00 Clip, Governor Gear 1
24 21.110012.01 Bushing, Govorner Gear 1
25 23.080600.00 Air Guide,Right 1
26 2.08.037 Bolt, Drain (M10Ч1.25Ч25) 2
27 2.03.016 Washer, Drain Bolt (10Чш16Ч1.5) 2
28 26.030100.00 Crankcase 1
29 21.120400.00 Diode Assembly 1
30 23.120700.02 Change wire flameout 1
31 21.127000.01 Oil Level Sensor 1
32 23.050200.00 Connecting Rod 1
33 25.050100.03 Crankshaft (Q) 1
34 1.276.6205 Bearing 6205 2
35 24.030008.00 Gasket, Crankcase Cover (No Asbestos) 1
36 22.031000.01 Oil Dipstick Assembly 1
37 24.030007.00 Cover, Crankcase 1
38 1.5789.0832.0.8 Flange Bolt (M8×32) 6
39 22.031000.00 Oil Filler Cap 1
40 23.110005.01 Spring, Throttle Return 1
41 21.110003.00 Arm, Governor 1
42 1.6177.06 Nut M6 3
43 2.03.021.1 Washer (ш6.4Чш13Ч1) 1
44 21.110001.00 Shaft, Governor Arm 1
45 22.123000.01 Ignition Coil (Shield) 1
46 1.5789.0625 Flange Bolt M6×25 2
47 23.110006.00 Rod, Governor 1
48 23.110007.00 Spring, Governor 1
49 2.08.040 Bolt, Governor Arm (M6×21) 1
50 21.110008.00 Pin, Shaft 1
51 24.111008.01 Grip Sheath, Speed Governor 1
52 24.111000.01 Control Assembly 1
53 25.040013.00 Lifter, Valve 2
54 2.04.001 Dowel Pin (ш9Ч14) 2
55 26.041000.01 Camshaft 1
56 2.14.012 Key (4Ч7.5Ч19) 1
57 26.050005.00 Piston 1
58 23.050003.00 Wrist Pin 1
59 2.09.001 Circlip (ш18Чш1) 2
60 26.050303.00 Ring, Oil 1
61 26.050302.00 Ring, Second Piston 1
62 26.050301.00 Ring, First Piston 1
63 26.030009.00 Gasket, Cylinder Head 1
64 2.04.003 Dowel Pin (ш10Ч14) 2
65 23.040002.00 Valve, Intake 1
66 23.040006.00 Valve, Exhaust 1
67 26.080400.00 Air Guide, Lower 1
68 2.15.002 (F6RTC) Spark Plug (F6RTC) 1
69 1.5789.0855 Flange Bolt M8×55 4
70 23.040017.00 Oil Seal, Valve 2
71 21.040003.00 Spring, Valve 2
72 21.040007.00 Retainer, Exhaust Valve Spring (up) 1
73 21.040001.00 Retainer, Intake Valve Spring (up) 1
# Part Number Description Qty
74 21.040008.00 Rotator, Exhaust Valve 1
75 24.040202.00 Shaft, Rocker Arm 1
76 22.040009.00 Rocker Arm, Intake Valve 2
77 22.040012.00 Screw, Valve Adjustment 2
78 21.040021.00 Nut, Lock 2
79 1.97.1.06 Washer (ø6) 6
80 1.6177.1.06 Nut M6 2
81 24.040201.00 Retainer, Rocker Arm 1
82 23.040010.00 Bolt, Rocker Arm 2
83 24.040004.00 Guide Plate, Push Rod 1
84 23.040005.00 Push Rod 2
85 21.020002.01 Gasket, Cylinder Head Cover (CPE) 1
86 24.021000.00 Cylinder Head Cover (CPE) 1
87 21.020001.00 Breather Tube 1
88 1.5789.0615 Flange Bolt M6×15 4
89 2.01.010 Stud Bolt (M8×35) 2
90 26.100001.00 Ex Pipe Gasket 1
91 1.16674.0510 Flange Bolt M5×10 2
92 1.848.05 Washer ø5 2
93 1.93.05 Spring Washer ø5 2
94 24.101202.00 Muffler Protector 1
95 46.101300.05 Spark Arrester 1
96 1.818.0406 Bolt M4×6 4
97 1.9074.4.0510 Bolt M5×10 2
98 24.101000.00 Muffler Assembly 1
99 1.93.06 Lock washer ø6 6
100 1.6175.08 Nut M8 2
101 1.848.08 Washer ø8 2
102 1.93.08 Spring Washer ø8 2
103 26.010100.00 Cylinder Head 1
104 2.01.009 Stud Bolt (M6×110) 2
105 24.130002.00 Gasket, Insulator (No Asbestos) 1
106 23.130001.00 Insulator, Carburetor 1
107 22.130003.00 Gasket, Carburetor (No Asbestos) 1
108 26.131000.00 Carburetor 1
109 21.130004.00 Gasket, Air Cleaner 1
110 21.130100.00 Choke Handle 1
111 24.091100.01 Base, Air Cleaner 1
112 1.5789.0620 Flange Bolt M6×20 5
113 24.091003.02 Element, Air Cleaner 1
114 24.091200.02 Cover, Air Cleaner 1
115 24.091600.01 Screw cap, Air clean Cover 2
116 22.070014.00 Pipe, Reversal Valve 1
117 2.06.006 Clip (ш7Чш1) 1
118 22.070013.00 Pipe, Air Cleaner
119 24.070700.00 Carbon Canister 1
120 1.845.2965 Screw ST2.9×6.5 2
121 2.03.037 Washer (ш3.2Чш14Ч1) 2
122 24.070100.02 Fuel Tank Cap 1
123 81.070301.00 Fuel Filter 1
124 1.5789.0629 Flange bolt M6×29 1
125 24.071000.01 Fuel Tank 1
126 111.070300.01 Fuel Filter Complete 1
127 2.06.018 Clip(ø10.5×b8) 1
128 24.070400.00 Fuel Valve 1
129 24.070011.01 Pipe, Fuel 1
130 24.070010.00 Fuel Tank Veil 1
131 5.1010.002.3 Flameout Switch 1
132 24.070001.00 Fuel Valve Knob 1
133 1.818.0412 Bolt M4×12 1
134 1.16674.0512.2 Flange Bolt M5×12 1
135 2.06.007 Clip ø8 3
136 24.070011.00 Pipe, Fuel 1
137
26.131017.00 Standard Main Jet 1
26.131017.00.01 Altitude Main Jet /
138 22.061000.00 Recoil Assembly 1
139 24.101000.00 Muffler Assembly 1
140 24.091000.02 Air Cleaner Assembly 1
141 2.12.001 Buffer (ш7.5Ч7.5) 1
