Champion Power Equipment 100156 - Manual (Page 21)

18
100156 ENGLISH Parts List
# Part Number Description Qty
1 1.9074.4.0516.1 Screw M5×16, Black 4
2 2.08.052.1 Bolt (M6×16) 10
3 83.200200.01.2 Cover, Left, Black 1
4 83.201600.03 Supporter, Left 1
5 1.5789.0612 Flange Bolt M6×12 10
6 83.200701.02.2 Handle, Left, Black 1
7 1.9074.4.0512.1 Screw/Washer Assembly M5×12, Black 11
8 83.200500.01.2 Cover, Top, Black 1
9 83.200502.01 Spillway, Fuel Tank 1
10 83.070100.01 Fuel Tank Cap 1
11 2.06.016 Clamp (Ø8.7×b8) 3
12 83.070011.01 Fuel Pipe, Fuel Tank To Fuel Valve 1
13 2.06.018 Clip (Ø10.5×b8) 1
14 111.070300.01 Inline Fuel Filter Assembly 1
15 2.08.068.2 Flange Bolt M5×13 6
16 83.071000.01 Fuel Tank 1
17 83.070300.01 Fuel Filter Assembly 1
18 83.070014.01 Pipe, Fuel Tank To Canister 1
19 1.845.4213 Screw ST4.2×13 6
20 83.081400.01 Muffler Protector Assembly, Upper 1
21 83.081004.01 Plate 1
22 2.02.001 Nut (M6), Long 2
23 83.100001.01 Gasket, Exhaust 1
24 83.101100.02 Muffler Assembly 1
25 46.101300.08 Spark Arrester Assembly 1
26 46.101503.08 Plate, Spark Arrester 1
27 1.9074.4.0514 Screw/Washer Assembly M5×14 2
28 1.845.4816 Screw ST4.8×16 6
29 1.845.4219 Screw ST4.2×19 1
30 83.081500.01 Muffler Protector Assembly, Lower 1
31 83.100501.01 Tube, Secondary Air Intake Valve 1
32 2.06.013 Clamp (Ø13.5×b10) 2
33 1.16674.0616 Flange Bolt M6×16 2
34 1.93.06 Lock Washer Ø6 3
35 1.5789.0620 Flange Bolt M6×20 6
36 83.100500.01 Supporter, Secondary Air Intake Valve 1
37 24.100003.03 Gasket, Air Supply Valve 1
38 24.100300.03 Secondary Air Intake Valve 1
39 2.08.055.1 Bolt, Maintenance Cover, Black 2
40 83.200402.01.2 Protector, Rear Cover, Black 1
41 83.200401.01.2 Supporter, Rear Cover, Black 1
42 2.02.014 Nut (M6), Square 12
43 2.02.010 Cage Nut (M5) 8
44 83.200701.03.2 Handle, Left, Black 1
45 83.200704.01.2 Bracket, Left, Black 1
46 83.201600.05 Supporter, Right 1
47 1.5789.0615 Flange Bolt M6×15 9
48 1.6187.1.08 Flange Lock Nut M8 2
49 2.13.001 Bushing Ш13.3ЧШ19.3Ч8 2
50 1.5789.0612.1 Flange Bolt M6×12, Black 4
51 83.200704.02.2 Bracket, Right, Black 1
52 2.03.001 Bushing (Ш13.3ЧШ19.3Ч2) 2
53 2.03.002 Washer (Ш13ЧШ20Ч2.5) 2
54 2.08.002 Bolt (M8×28) 2
55 83.200701.04.2 Handle, Right, Black 1
56 2.02.002 Nut (M6), T-Style 2
57 83.200705.01.2 Handle, Upper, Black 1
58 83.200705.02.2 Handle, Lower, Black 1
59 1.9074.3.0512.1 Screw M5×12, Black 3
60 1.5789.0635.1 Flange Bolt M6×35, Black 2
61 83.190006.01 Rubber Sleeve, End Cover 1
62 83.190003.01 Generator End Cover 1
63 83.190001.01 Generator Fan 1
64 2.02.006 Nut M14×1.5 1
65 83.191100.01 Rotor Assembly 1
66 1.5789.0645 Flange Bolt M6×45 4
67 83.191200.01 Stator Assembly 1
68 83.190002.01 End Cover, Motor 1
69 83.401 Engine 1
70 1.6177.1.08 Flange Lock Nut M8 12
# Part Number Description Qty
71 2.05.050 Wire Clip, 100mm 2
72 83.201600.02 Supporter, Left 1
73 83.201600.01 Supporter, Right 1
74 83.201200.01 Motor Mount 4
75 83.200607.01 Plug 1
76 1.6182.06 Lock Nut M6 6
77 83.200601.01 Base Setting Component 1
78 83.200609.02 Steel Plate (II) 2
79 83.200609.01 Steel Plate (I) 2
80 83.201400.01 Rubber 2
81 83.201702.01 Plug, Wheel 2
82 1.894.1.12 Retaining Ring Ø12 2
83 1.848.12 Washer Ø12 2
84 83.201701.01 Wheel, Left 1
85 83.201500.01 Axle 1
86 83.201701.02 Wheel, Right 1
87 83.200305.01 Spring Patch 5
88 83.200304.01 Rubber Seal Sleeve 1
89 1.845.3595 Screw ST3.5×9.5 9
90 83.200303.01.2 Cover, Right Muffler, Black 1
91 83.200701.01.2 Handle, Right, Black 1
92 83.200302.01.2 Cover, Right Side, Black 1
93 2.08.075.1 Bolt M6×20 2
94 81.220002.00 Mount Rubber, Control Unit 2
95 81.220001.00 Protector, Control Unit 2
96 83.220003.01 Pinch, Control Unit 2
97 83.221000.00 Control Unit (120V/60Hz) 1
98 1.5783.0520 Bolt M5×20 1
99 1.93.05 Lock Washer Ø5 1
100 5.1800.003 Rectifier 1
101 83.070013.01 Pipe, Canister To Air Cleaner 1
102 46.070700.00 Carbon Canister (150CC) 1
103 83.070702.01 Support Arm 1
104 83.070011.02 Fuel Pipe, Fuel Valve To Carburetor 1
105 1.845.4819 Screw ST4.8×19 2
106 1.97.1.05 Washer Ø5 2
107 83.070400.01 Fuel Valve 1
108 83.200101.01.2 Front Cover, Black 1
109 83.200106.01 Protector 1
110 83.061200.01.2 Guide, Rope, Black 1
111 1.823.0408.1 Screw M4×8, Black 2
112 83.070001.01 Fuel Valve Knob 1
113 83.130200.01 Pull Chock Assembly 1
114 100156.21 Control Panel Assembly 1
115 83.01.24.2 Control Panel, Black 1
116 5.1210.920 A.C 20A Breaker, Push Button 1
117 1.9074.4.0414.1 Screw/Washer Assembly M4×14, Black 2
118 1.6177.1.04.1 Flange Lock Nut M4, Black 6
119 5.1120.050 Receptacle 5-20R Duplex, GFCI 1
120 5.1870.005 Receptacle Cover, Receptacle 5-20R, Duplex, GFCI 1
121 122.210003.01 Wire Jacket, Control Box 1
122 83.210002.02 Control Box 1
123 100156.21.10 Wire Assembly 1
124 1.9074.4.0535 Screw M5×35 2
125 1.818.0514.3 Screw M5×14, Green 2
126 5.1870.004 Receptacle Cover, Receptacle TT-30R 1
127 5.1120.036 Receptacle TT-30R 1
128 5.1000.002.1 Ignition Switch, Black 1
129 83.210016.00 Speed Limiter 1
130 5.1010.001.1 Switch, Economy 1
131 1.5783.0514.3 Bolt M5×14, Green 1
132 1.862.05 Lock Washer Ø5 1
133 1.97.1.05.3 Washer Ø5, Green 2
134 1.93.05.3 Lock Washer Ø5, Green 2
135 1.6170.05.3 Nut M5, Green 2
136 5.1110.005 Receptacle (DC.12V) 1
137 5.1200.110.1 Breaker (10A) 1
138 9.1700.003 Plug (USB 5V/2.1A) 1
139 9.1600.012 Cables, 12V, 2m 1
