Camcorp Reverse Air Components
Item Quantity Description
1A
1 Sweep Arm (Size Determined by Unit)
1B
1 Sweep Arm (Size Determined by Unit)
2
1 8” OD Rotary Spool Section
3
1 8” OD Arm Rotation Support
4
1 8” OD Fan Exhaust Air Stub
5
1 8” Straight Rubber Hump
6
1 Fan Channel Support
7
1 Reverse Air Fan (Size Determined by Unit Size)
8
4 Vibration Isolation Supports
9
2 Fan Support Wall Bracket
10
4 Drive Mount Table Wall Brackets
11
2 Drive Mount Table Support Channel
12
1 50TTA2635 x 1” Sprocket & TTA35BS x 1 “ Torque Limiter Clutch
13
1 50A58 Drive Sprocket
14
1 Roller Chain Tensioner
15
1 206 Gearbox Drive Shaft
16
3 Motor, ½ HP, TEFC 1,800 RPM, 56C, 208-230/460/3/60
17
1 Primary Gear Reducer, 133Q56R20, 20:1 Ratio
18
1 Secondary Gear Reducer, 206Q56L40, 40:1 Ratio
19
1 Bracket Kit, 206S-BK (Secondary Reducer)
20
1 Drive Mount Support Table
21
1 4-Bolt Flange Thrust Bearing, 1 ½”
22
1 Bearing Mounting Plate
