Center High-Mounted
Stoplamp (CHMSL)

It is recommended that this component be replaced as
a unit. See your dealer.

Taillamps and Turn Signal Lamps

1. Open the trunk to gain access to the lamp housing.

2. Remove the rear

compartment sill plate
by removing the
upper convenience net
retainers, located at
each end, as shown.

3. Move the spare tire cover out of the way.

4. Pull the trunk trim away to access the wing nuts.

5. Remove the three wing nuts that fasten the taillamp

to the body.

6. Gently remove the taillamp from the body. The

taillamp is on the bottom of the housing and the
rear turn signal lamp is on the upper part of
the housing.
