Bullet Tools 209 - Manual (Page 5)

5
SET Up
4
6
5
Fasten the Rail Support
Tabs to the Base with
two (2) M6 x 8mm Phillips
head machine screws�
Tightly secure the handle
to the camshaft using four
(4) M8 x 20mm sockethead
machine screws with an
M6 Allen wrench. (Included)
To attach extension,
push spring-button and
slide handle stub into
lower handle until the
spring-button clicks into
place.
M8 x 20
M6 x 8
3
#12 x 1”
Attach rail to table using
(4) #12 x 1” Phillips head
screws and tighten with a
#3 screwdriver.
Push in
