Centro G51210 - Manual (Page 7)

10 11
ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS
11
10
9
YOU WILL NEED:
12
Attach the left shelf fascia (DB) to the left side shelf
table (DA).
DA
DB
Front
DA
DB
*
A
B
TIP: To position the left side shelf, insert the two
hooks on the side shelf assembly into the two
openings located on the upper left side panel
(BB).
Assemble the right side shelf assembly to the cart
assembly, as shown in fi gure B.
BB
Remove the hardware that is pre-assembled to the
side burner valve bracket (CC), as shown in fi gure
A. Insert the side burner valve stem through the
rear of the left side shelf fascia (DB). Assemble the
side burner valve (CC) to the side shelf fascia (DB),
using the hardware removed.
Assemble the side burner control knob (#12) to
the side burner valve (CC).
Hardware may be included with the hardware
pack.
DA
DB
12
CC
A
8 7 6
YOU WILL NEED:
6 7 8
X 3 X 3 X 3
X 1
YOU WILL NEED:
A
A
B
B
B
B
B
2
3
4
4
5
5
X 1 X 1 X 1
X 4 X 4 X 4
11
X 2
B
