SET-UP GUIDE
The BOOMCHAIR™ comes with the following:
PARTS LIST:
3b
3a
3c
DASHBOARD CONTROL PANEL
1
2
5
7
6
8
9a
4
1) BOOMCHAIR™
2) POWER SUPPLY (UL Listed)
3a) RCA TO MINI AUDIO CORD
(headphone jack to audio left & right channel connectors)
3b) RCA CORD (audio left & right channel connectors)
3c) RCA AUDIO COUPLER
4) POWER RECEPTACLE
5) HOOK & LOOP FASTENER
6) PADDED COMFORT ZONE
7) ADJUSTABLE RECLINE STOPPERS
8) DASHBOARD CONTROL PANEL
9a) SPEAKERS (2)
9b) SUBWOOFER (1)
Dimensions: 23 in. L x 26.5 in. W x 33.5 in. H
58.4 cm. L x 67.3 cm. W x 85.1 cm. H
Weight: 48 lbs. / 21.8 kgs.
2 x 3 in. (7.5 cm.) coaxial mid-high speakers @ 3W 4 Ohms
1 x 4 in. (10 cm.) subwoofer speaker @ 15W 4 Ohms
Power rating: 12 V AC @ 1830/mA
SYSTEM SPECS:
(A) POWER SWITCH / VOLUME CONTROL
(B) BASS/TREBLE CONTROL
(C) RCA AUDIO OUTPUTS
(D) RCA AUDIO INPUTS
9b
LED POWER
INDICATOR
