F-20843 4 1-12-11
CAUTION
DANGER
are in good condition. Inflate tires to proper
recommended air pressure. It is recommended
that a ROPS (Rollover Protection System) be
installed on all tractors. Contact you local dealer
for a ROPS for your tractor model.
Tractor should be equipped with stabilizer bars,
adjustable sway chains, or sway blocks to keep
the One Row Cultivator from swinging side to
side.
Be sure your tractor is in good working
condition. Read all the safety procedures and
make sure all tractor operators are familiar
with the safety rules of operation.
Assembly& Mounting
The One Row Cultivator is shipped assembled.
The holes in the frame angle will allow the shanks
to be located with different spacing. Make sure
that all shanks are symmetrically spaced.
Make sure the lower draw pins (pull pins) are
installed correctly for your tractor. Insert the draw
pins into the ball sockets in the lower lift arms
of the tractor 3-Point hitch. Lock into place with
lynch pins. Attach the mast of the 3-Point main
frame by installing the tractor top link. with the
top link pin.
Adjust the top link assembly to obtain the correct
angle of the implement. Check the tractor 3-Point
lift arms and adjust to level the implement from
side to side.
Never allow anyone to ride or sit on implement
or tractor while in operation. Keep bystanders
at a safe distance.
Preparation Procedure
• Thoroughly read and understand your
Operator’s Manuals.
• Before beginning operation, contact your local
Utility Company to make certain there are no
gas lines, electrical cables, etc., in the work
area.
• Check for ditches, stumps, holes, or other
obstacles that could cause the tractor to roll.
• Be sure tractor tires and rims are in good
condition. Inflate tires to proper air pressure.
• All persons should be at least twenty-five feet
(25’) away during operation. Clear the area of
helpers, bystanders, and especially children.
• Do NOT allow anyone to stand between the
hitch and implement.
• It is recommended that only tractors with
wide front axles use the One Row Cultivator.
Tricycle front wheel arrangements are inherently
unstable and can cause rollover accidents.
• Check the tractor master shield over the PTO
stub shaft. Make sure it is in good condition and
fastened securely to the tractor.
• Make sure all safety stickers are installed and in
good condition. Replace if damaged.
• Do NOT allow riders. There is no safe place for
anyone to ride or sit on tractor or implement.
• Check that all equipment is properly installed
and securely attached to the tractor.
Operation
If you have any questions regarding the
proper operation of this One Row Cultivator,
contact your dealer or the manufacturer.
The design and tested safety of this machine
depends on it being operated within the
limitations as explained in this manual. Be
familiar with and follow all safety rules in this
manual for the implement as well as your tractor.
Safe operation of this machine is the
responsibility of the owner/operator. The operator
should be familiar with the One Row Cultivator
and tractor and all safety practices before starting
operation. Read the entire owners manual.
Never let anyone stand between the rear of the
tractor and the implement while the tractor is
backing up to connect to the implement.
Always stand to the side until the tractor has
come to a complete stop and the brakes are set
or the tractor is in “park”.
Allow additional clearance for the implement to
swing when turning. Check for stumps, ditches,
holes or other obstacles that could tip tractor or
damage the Cultivator.
For proper operation, level the Cultivator by
