P. 4
HEADPHONE SYSTEM PARTS LIST IDENTIFICATION
1 RF transmitter
2 RF receiver headphones
3 Power On/Off switch
4 Power On indicator light
5 Rechargeable 1.2 V 500 mAh batteries (Ni-MH, LR03/AAA size)
6 Charge contacts
7 12V 150 mA AC power adapter (UL LISTED)
8 Jack plug adapter (3.5 mm/6.3 mm diameter)
9 RCA socket audio adapter cable, (3.5mm input jack to two RCA plugs)
10 Operating indicator light (power)
11 Charge indicator light (charging)
12 Audio connection cable with 3.5mm jack
13 Volume control knob (VOL)
14 AUTO SCAN indicator
15 AUTO SCAN button
16 Battery door
17 DC IN connector
18 Audio input cable
19 Channel selector (CHANNEL 3 2 1)
P. 5
Before Using the Headphone System
An initial 24-hour charge is required to ensure an acceptable service life for the
rechargeable batteries. Always ensure that the headphones are switched to the Off
position while the batteries are charging.
INSTALLATION
RECEIVER HEADPHONES
1. Open the cover of the rechargeable battery compartment located on the side of the
right-hand receiver headphone.
2. Insert two rechargeable LR03/AAA size batteries taking care to ensure correct
polarity.
3. Close the battery compartment cover.
TRANSMITTER
1. Connect the provided AC/DC power to an electrical outlet.
2. Connect the AC/DC power adapter cable to the DC IN input connector located on
the transmitter rear panel.
3. Plug in the AUDIO IN cable located on the back of the transmitter panel to a
headphones/earphones output on your TV, stereo system, VCR, PC, or radio.
Depending on the size of the Audio Out port of your audio component, you may need
to use the included Jack Plug Adapter. If the stereo (or other audio component) has a
two-hole Audio Out (left and right) connection, use the RCA socket audio adapter
provided. Connect it to the end of the AUDIO IN cable and then to the Audio Out
connection on the component making sure to match the RED to RED and the WHITE
to WHITE.
4. A cable is provided from the transmitter rear panel that can be connected to the audio
output (left and right) on a TV, stereo system, VCR or radio, or to a
headphones/earphones output using the connector supplied.
” Note: You may need the included iPhone Adapter to connect your iPhone to the
transmitter for audio streaming. Simply plug the cable from the transmitter into one
end of this iPhone Adapter, then plug the other end of the adapter into your
iPhone. ”
