AquaCraft Motley Crew - Manual (Page 3)

3
FEATURES & SPECIFICATIONS
MOTLEY CREW FEATURES:
Hand laid fi berglass hull and canopy
Drop tub design
Roomy interior
Tactic 2.4GHz radio system
AquaCraft 1800 KV 6 pole motor
AquaCraft 60amp Motor Controller (ESC)
Aluminum water jacket
Black anodized aluminum hardware
Transom mounted water cooling pickup
Hook and loop battery mounting
Registered Motley Crew graphics
Other standard features include:
High gloss painted fi nish
Brass stuffi ng tube
Low friction cable guide
.150" fl ex drive cable
Industry standard 3/16" (.187") prop shaft
42mm Fiber Reinforced Plastic (FRP) Propeller
BASIC HULL SPECIFICATIONS:
Hull Length: 29-3/4" (756mm)
Overall Length: 32" (813mm)
Width: 10-1/2" (242mm)
Height (Less Hardware): 6" (153mm)
Empty Weight: 4.18lb or 67oz (1.89kg)
Weight RTR: 5.53 lb or 88.5oz (2.50kg) (weight taken with
Marine Power 5000mAh LiPo packs)
MOTOR SPECIFICATIONS:
Diameter: 36mm
Length: 56mm
Shaft Length: 15mm
Overall Length: 71mm
Shaft Size: 5mm
Connectors: 4mm Bullet
Weight: 212g Input Voltage: 7-18.5v
Max. Constant Current: 50A
Max. Surge Current: 80A/fi ve
seconds
No Load Current: 5.0A
kV Rating: 1800 rpm/V
Watts: 925Max
ESC SPECIFICATIONS:
Length: 100mm Width: 38mm
Height: 17mm Weight: 3.8oz (109grams)
Wire Gauge: 14g
Battery Connectors: Male Deans
® Ultra ® Plugs (2)
Motor Connectors: 4mm gold plated bullet connectors (3)
Input Voltage: 12-14 NiMH
4 cells LiPo
8-20V input w/o BEC)
Output Current: 60A continuous maximum
72A surge maximum
Max Output Power: 720 watts
On-Resistance: 0.003 ohms
Operating Frequency: 8kHz
BEC: 5.2V/2A
Stutter Bump Voltage: 12V Low Voltage Cutoff: 11.6V
Thermal Cutoff: 110C Timing Angle: 10°
WARRANTY SERVICE
AquaCraft will warrant your model for 90 days after the purchase
from defects in materials or workmanship of original manufacture.
AquaCraft, at their option, will repair or replace at no charge, the
incorrectly made part. This warranty does not cover damage caused
by crash, abuse, misuse, alteration or accident. To return your boat
for service you need to provide proof of purchase. Your store receipt
or product invoice will suffi ce.
IN NO EVENT SHALL THE PURCHASER BE ENTITLED TO ANY
INCIDENTAL, SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES,
WHETHER RESULTING FROM THE USE, MISUSE OR INABILITY TO
USE THE PRODUCT OR FROM DEFECTS IN THE PRODUCT.
This warranty gives you specifi c legal rights and you may also have
other rights, which vary from state to state.
Outside USA and Canada, contact local importer for warranty
information.
Hobby Services
3002 N. Apollo Drive, Suite 1
Champaign, Illinois 61822
Attn: Service Department
Phone: (217) 398-0007 9:00 am - 5:00 pm Central Time M-F
E-mail: [email protected]
SAFETY PRECAUTIONS
➧ Never, ever, attempt to swim after a stalled RC boat. DO NOT get
in the water for any reason to retrieve your boat. Your Motley
Crew has fl otation added to the interior of the hull and the cowl.
It will not sink. To aid you in retrieving a stalled RC boat you can
use a fi shing reel with a tennis ball tied to the end of the line. Or
better yet, get yourself a small Jon boat so you can row out and
pick up your boat. Remember to use a PFD any time you enter
your retrieval craft.
➧ Do not touch the propeller anytime the motor is running. Pay equally
close attention to items such as loose clothing, shirtsleeves, ties,
scarves, long hair or anything that may become entangled in the
spinning prop. If your fi ngers, hands, etc. come in contact with the
spinning propeller, you may be severely injured.
➧ The speed and mass of this boat can infl ict property damage and
severe personal injury if a collision occurs. Never run this boat
in the presence of swimmers or where the possibility of collision
with people or property exists.
➧ This boat is controlled by radio signals, which are susceptible to
possible interference from RF sources. It is a good idea to pre-
check the system to make sure it’s operating properly before you
launch your boat.
➧ If your boat should happen to stall, water currents will slowly
carry it to shore. The bad news is the boat could be carried to the
opposite shore. When surveying areas to run your model, keep
variables in mind such as wind direction, size of the lake, etc. It is
not advisable to run R/C boats on any free-fl owing bodies of water
such as creeks or rivers.
