Crown Boiler PET708 User Manual
Page 2
DIMENSIONS and SPECIFICATIONS
MSS79
MSS119
1
Cold Water Inlet
1 M
1-1/4 M
2
Lower Coil Return
3/4 M
3/4 M
3
Lower Coil Supply
3/4 M
3/4 M
4
Upper Coil Return
3/4 M
3/4 M
5
Upper Coil Supply
3/4 M
3/4 M
6
Hot Water Outlet
1 F
1-1/4 M
7
Additional Tank Tapping
1-1/4 F
1-1/4 F
8
T&P Valve Tapping
1 F
1 F
9 & 10
Control Well
N/A
N/A
Size (NPT)
CONNECTIONS
Key #
Description
Coil Surface
Sq. ft.
A
B
C
D
E
F
G
H
I
J
K
Upper/Lower
MSS-79S
76
2
10
21-3/4
26
35
42-1/4 50-1/2 56-1/2 59-1/2 24 68-3/4
9.47/10.14
126
MSS-119S
116
2 11-1/2 22-1/2 27-1/2 30-1/4
35
46
49-1/4 52-1/2 29
67
9.47/10.14
210
Weight
(lbs)
Model
Approx.
Volume
(Gal)
Dimensions in Inches
3633 I Street, Philadelphia, PA 19134
Phone: (215) 535-8900 Fax: (215) 535-9736
email: [email protected] website: www.crownboiler.com
4/09
