11
-ANTARI On-Board DMX Module Settings
There are 3-pin and 5-pin male/female DMX control sockets for connecting your selection located
at the rear panel of the X-310PRO fazer. The X-310PRO Fazer has on-board DMX control. This model
uses two channels to control Volume output and Fan speed. Whatever channel you select on the
unit, the channel next to it will automatically be selected for fan volume control. The X-310PRO fan
has three fan speeds: Slow, Medium, and Fast. If the machine was assigned to the DMX address
124 e.g., Channel A would correspond to DMX address 124 and channel 125 will automatically be
selected for fan control.
Please note: Your X-310PRO Fazer and its liquid tank and tube were thoroughly tested and cleaned.
When operating the unit for the time, please press the button
MANUAL for 3 to 5 seconds to
let the unit circulate. Please do not try to set the timer function on your first operation. In addition,
it is normal for the machine to produce some pumping sound for about 3 to 5 seconds. After the
machine is operating smoothly you can start to set the desired operating functions. In future, it is
strongly recommended to empty the liquid tank before transporting and follow the methods
mentioned above for machine circulation after each transportation.
Channel A (Fan speed)
MEDIUM
Value Func tion
86-170
SLOW 0-85
FAST 171-255
In general, fan speed and fog density are in reverse propotion. For example, if you are operating
at 100% fog output, and fan speed is slow, heavy fog is being produced. When fan speed is high,
fog density is consequently lighter/more transparent.
Channel B (Volume control)
Volume Control (5 % - 100 %)
Value Func tion
6-255
OFF(0% )
0-5
If Channel B has a value from 0 to 5, the unit is OFF.
Between the values 6 to 255 the volume of fog output is regulated. With 6 being the minimum
volume of fog produced and 255 the maximum. The volume output rises as the DMX value is
increased. The Antari X-310PRO Fazer can produce maximum continuous output.
-Maintenance & Storage
 Do not allow the fog liquid to become contaminated. Always replace the caps on the fog liquid
