Bluetooth™ Installation Guide
2. Set up of the Bluetooth™ connection to the instrument
Insert the Bluetooth™ adapter into a free USB port
of the PC.
Switch on the instrument and if needed, activate
the Bluetooth™ function of the unit (for details
refer to the instrument manual).
Right click on the Bluetooth™ symbol in the task
bar of the computer or go to the Programs folder
of the “Start“ menu, and select “Bluetooth™ -
Settings“.
Activate “New Connection“, select “Express
mode“ and follow the instructions on the screen.
The Bluetooth™ manager starts to scan for
Bluetooth™ devices.
A dialog box appears which lists all available
devices.The measuring unit is identified by its
name and serial number. These data can be
verified on the instrument label. Highlight the
desired instrument and continue with “Next“.
Passkey (PIN)
If a box appears asking for the Bluetooth™
Passkey (PIN), enter “0000“ for the instrument and
confirm with “OK“.
The Bluetooth™ connection will be completed
and an information about the used COM port is
displayed.
Finally, the window “Bluetooth™ Settings“
appears with an icon included for the new
instrument, the connection will be ready to use.
