6
2. SPECIFICATION
Dimensions:
Length: 13’
Width: 32”
Weight: 42 lbs (19 kg)
Max. Person Capacity: 400 lbs (181 kg)
Max. Persons & Gear Capacity: 450 lbs (204 kg)
Recommended Pressure:
Main chambers: 2.0 psi (0.14 bar)
Floor chamber: 1.0 psi (0.07 bar)
2.1 Capacity
The person/load capacity is determined by the availability of proper seating on the kayak.
Acceptable seating determines the number of passengers, not the overall load capacity.
MAXIMUM CAPACITIES
450 LBS PERSON, GEAR
PRESSURE = 2.0 psi (main chambers)
MANUFACTURER: ADVANCED ELEMENTS, INC. CONCORD, CA USA 94524
MODEL AE1009 - ADVANCEDFRAME EXPEDITION™ KAYAK
COMPLIANCE
WITH
ISO 6185-1
TYPE III, A
0123
1
+ = 204 kg
0,14 bar (main chambers)
1
PERSON OR 400 LBS.
THIS BOAT COMPLIES WITH NMMA STANDARDS OF EFFECT
ON THE DATE OF CERTIFICATION
NATIONAL MARINE MANUFACTURES ASSN.
2010
NOT INTENDED FOR MECHANICAL PROPULSION
AdvancedFrame Expedition™ Kayak Capacity Label
WARNING: Do not exceed the certified maximum capacities under any circumstances.
Overloading will reduce freeboard and increase the likelihood of swamping, especially in heavy
seas. Overloading causes handling to become sluggish, making it difficult to react quickly.
2.2 Features
Good Stability: Low center of gravity design provides good stability and easy paddling.
Multiple Chambers: 9 Chambers provide additional buoyancy and unique kayak shape.
Easy to Set Up: New Twistlok™ valves and high flow Spring™ valves allow for quick setup time.
Comfortable: Raised deck and adjustable lumbar seat provide comfort for hours of paddling.
Hull Design: Built-in Aluminum ribs define the bow and stern and improve tracking.
