6
2. SPECIFICATION
Dimensions:
Length: 10’5”
Width: 34”
Weight: 36 lbs (16 kg)
Max. Person Capacity: 235 lbs (107 kg)
Max. Persons & Gear Capacity: 300 lbs (136 kg)
Recommended Pressure:
Main chambers: 2.0 psi (0.14 bar)
Floor chamber: 1.0 psi (0.07 bar)
2.1 Capacity
The person/load capacity is determined by the availability of proper seating on the kayak.
Acceptable seating determines the number of passengers, not the overall load capacity.
MAXIMUM CAPACITIES
300 LBS PERSON, GEAR
PRESSURE = 2.0 psi (main chambers)
MANUFACTURER: ADVANCED ELEMENTS, INC. CONCORD, CA USA 94524
MODEL AE1012 - ADVANCEDFRAME™ KAYAK
COMPLIANCE
WITH
ISO 6185-1
TYPE III, A
0123
1
+ = 136 kg
0,14 bar (main chambers)
1
PERSON OR 235 LBS.
THIS BOAT COMPLIES WITH NMMA STANDARDS OF EFFECT
ON THE DATE OF CERTIFICATION
NATIONAL MARINE MANUFACTURES ASSN.
NOT INTENDED FOR MECHANICAL PROPULSION
2010
AdvancedFrame™ Kayak Capacity Label
WARNING: Do not exceed the certified maximum capacities under any circumstances.
Overloading will reduce freeboard and increase the likelihood of swamping, especially in heavy
seas. Overloading causes handling to become sluggish, making it difficult to react quickly.
2.2 Features
Hull Design: Built-in Aluminum ribs define the bow and stern and improve tracking.
Durable: 3 Layers of material for extreme puncture resistance.
Easy to Set Up: Pre-assembled at the factory. Simply unfold, inflate and attach the seat.
Comfortable: High support, adjustable padded seat provides comfort for hours of paddling.
Style: Looks and paddles similar to a rigid hard-shell kayak with the portability of an inflatable.
