Amps. No. Circuits Protected Amps. No. Circuits Protected
15 A
10 A
7.5 A
7.5 A
7.5 A
15 A
7.5 A
7.5 A
7.5 A
7.5 A
15 A
30 A
7.5 A
1
2
3
4
5
6
7
8
9
10
11
12
13
On Canadian models
Driver’s Power Window
Heated Seat
Driver’s Power Seat Slide
Front Passenger’s Power
Seat Slide
Front Passenger’s Power
Seat Reclining
Rear Left Power Window
Front Passenger’s Power
Window
ACC (Radio)
Navigation System, OnStar,
Daytime Running Lights
Power Door Locks
Clock, Back up
A/C Mg Clutch
Moonroof
Rear Right Power Window
20 A
20 A
20 A
20 A
20 A
20 A
20 A
20 A
20 A
10 A
7.5 A
20 A
7.5 A
7.5 A
30 A
20 A
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Fuel Pump
SRS
Heater Control, A/C Clutch
Relay, Cooling Fan Relay
R/C Mirror
Daytime Running Lights
ECU (ECM/PCM), Cruise
Control
SRS
ACC Relay, Navigation
Instrument Panel, Back-up
Lights, Memory Seat
Turn Signals
IG Coil
Wiper, Washer
Starter Signal
Type S only
1 :
2 :
Driver’s Power Seat Reclining
Interior Light, Courtesy Lights
1
2
1
Fuses
Taking Care of the Unexpected 311
INTERIOR FUSE BOXES
Driver’s Side
Passenger’s Side
