AUDIO / VIDEO CONNECTIONS
AV (Audio / Video) is a dedicated input for VCR’s, Sateiiite Receivers and other Audio / Video equipment.
This TV is capabie of switching to AV operation automaticaiiy if the equipment connected provides a switching signai to the SCART
socket.
In this condition the dispiay wiii show EC and it is possibie to change the programme position of the TV without changing the dispiayed
picture.
Video input
Audio input
to V socket
to A socket
RCA Video
Cabie
RCA Audio
Cabie
CAMCORDER
Output from
Headphone
Headphones
with 3.5mm
jack piug
Anciiiary equipment and cabies shown are not suppiied with this TV set.
Do not connect a computer with TTL output (5V) to this TV set.
The TV’s speaker wiii be automaticaiiy disconnected whiist the headphones are connected.
Do not connect front and rear AV inputs simuitaneousiy, as the sound and pictures wiii be mixed.
