Introduction
i
I ntroduction
Welcome
This chapter describes the organization, manual conventions,
and provides specification information .
Manual Conventions
Three kinds of special explanations appear throughout the manual —
Warning , Caution and Note. The format and significance of each is
defined below:
WARNING
Possible danger to people. Injury may result if this information is
ignored.
CAUTION
Possible risk to the product. The Load Disc or other equipment may be
damaged if this information is ignored.
Note
Contains additional information about a step or feature critical to the
installation or operation of the Load Disc.
About this manual
This manual describes the installation of the Load Disc 3xi/3xiC load cell and
its various hardware options. It includes procedures for leveling and shim-
ming of the vessel if it is neccessary. Instructions for wiring the load cell to
the junction boxes and wiring the junction boxes together and to the signal
processor are also included. Refer to the signal processor manual for specific
information on wiring the junction boxes to the signal processor.
Contact KM at 1-800-426-9010 if you have any questions regarding the
installation. For outside the USA and Canada, call 425-486-6600.
The chapters are organized in the following way:
Chapter 1: Description of the Load Disc 3xi/3xiC
Chapter 2: Preparing the Load Disc 3xi/3xiC for Installation
Chapter 3: Mounting the Load Disc 3xi/3xiC
Appendix A through D include contact info, system calibration, troubleshoot-
ing charts and technical drawings (TI’s).
