Cavity Fuse Circuit
1 30 Amp
Green Blower Motor
2 10 Amp Red Right High Beam Head-
light, High Beam Indica-
tor
3 10 Amp Red Left High Beam Head-
light
4 15 Amp
Blue Power Door Lock Switch
Illumination, Power Top
Switch, Transmission
Range Switch, Daytime
Running Light Module
(Canada), Power Win-
dows, Anti-lock Brake
System Module
Cavity Fuse Circuit
5 10 Amp Red Power Door Lock and
Door Lock Arm/Disarm
Switches, Vanity, Read-
ing, Map, Rear Seating,
Ignition, and Trunk
Lights, Illuminated Entry,
Radio, Power Antenna,
Data Link Connector,
Body Control Module,
Power Amplifier
6 10 Amp Red Heated Rear Window
Indicator
7 20 Amp Yel-
low Instrument cluster illumi-
nation, Park and tail
Lights
8 20 Amp Yel-
low Power Receptacle, Horns,
Ignition, Fuel, Start
9 15 Amp
Blue Power Door Lock Motors
(Body Control Module)
10 20 Amp Yel-
low Daytime Running Light
Module (Canada)
MAINTAINING YOUR VEHICLE 249
7
