II. Quick Overview: What’s What
Eobody2HF Receiver
The receiver is connected to your computer via USB. It receives the
sensor datae sent by the transmitter.
receiver tri-color LED
USB I/O
Eobody2HF Transmitter
Sensors are connected to the transmitter. The sensors are plugged to the 3 pins connectors.
Eobody2HF / Quick Overview: What’s What
sensor 3 pins connector
inputs 1 to 16
activity LED
on/off Battery charge via USB I/O
USB I/O for editing settings
via the editor
