Page 8 SKU 97743 For technical questions, please call 1-800-444-3353.
indicate it is acceptable for outdoor
use.
Make sure the extension cord is
6.
properly wired and in good electrical
condition. Always replace a damaged
extension cord or have it repaired by
a qualified electrician before using it.
Protect the extension cords from
7.
sharp objects, excessive heat, and
damp or wet areas.
REcOMMEndEd MiniMuM WiRE
gAugE FOR EXTEnSiOn cORdS*
(110/220 VOlT)
nAMEplATE
AMpERES
(at full load)
EXTEnSiOn cORd
lEngTH
25’ 50’ 75’
100’ 150’
0 – 2.0 18 18 18 18 16
2.1 – 3.4 18 18 18 16 14
3.5 – 5.0 18 18 16 14 12
5.1 – 7.0 18 16 14 12 12
7.1 – 12.0 18 14 12 10 -
12.1 – 16.0 14 12 10 - -
16.1 – 20.0 12 10 - - -
TABlE A
* Based on limiting the line
voltage drop to five volts at
150% of the rated amperes.
Symbology
Double Insulated
Canadian Standards Association
Underwriters Laboratories, Inc.
V~
Volts Alternating Current
A
Amperes
n
0
xxxx/min.
No Load Revolutions per Minute
(RPM)
SpEciFicATiOnS
Electrical
Requirements
120 V~ / 60 Hz / 620 W
2-Prong, Polarized Power Plug
Speed n
0
750/min
Blows Per
Minute
2920 BPM
Capacity 1”
Chuck Type SDS
Rotation Clockwise (non-reversible)
Applications
For drilling stone, concrete, and
other hard and brittle materials.
For chiseling.
Accessories
Wrench
SDS Drill Bits: 10mm/12mm
14mm/22mm
4-Point Chisel
Container of Grease
Carbon Brush Set
Depth Gauge Rod
Auxiliary Handle
Carrying Case
E194601
unpAcKing
When unpacking, check to make sure
that the item is intact and undamaged. If
any parts are missing or broken, please call
Harbor Freight Tools at the number shown
on the cover of this manual as soon as pos-
sible.
