13 106196
OWNER’S MANUAL
PARTS LIST This list contains replaceable parts used in your appliance. When ordering parts, follow the instructions listed
under Replacement Parts on page 10 of this manual.
PATIO FIRE
PC3460NG
KEY NO. PART NO. DESCRIPTION QTY.
1 106116-01 Burner Assembly 1
2 106117-01 Burner Plate 1
3 106118-01 Burner Plate Bracket 4
4 106119-01 Injector, NG 1
5 106725-02 Outlet Tube Assembly 1
6 106208-01 Gas Valve 1
7 098835-01 Nut, Valve Retention 2
8 106714-01 Outlet Adapter 1
9 57413 Street Elbow 1
10 099538-01 Thermocouple 1
11 106195-01 T-C Bracket, NG 1
12 106711-01 T-C Cover 1
13 099237-01 Retainer, T-Couple 1
14 106120-02 Front Mounting Plate 1
15 106121-02 Control Bracket 1
16 106130-01 Spark Module 1
17 106715-01 Grounding Wire 1
18 106134-01 Electrode 1
19 106123-01 Firepit 1
20 M10908-14 Screws, Sheet Metal 18
21 106716-01 Inlet Adapter Pipe Fitting 1
22 106712-01 Flex Supply Hose 1
23 106742-01 Switch 1
24 079010-14 Wire Harness, Switch 2
25 106718-01 Hose Clamp 1
26 079919-01 Dust Cover, Switch 1
PARTS AVAILABLE — NOT SHOWN
106204-01 Lava Rock 1
106046-01 Logs (Set of 6) 1
106717-01 Protective Cover 1
106749-02 Lighting Instructions Plate 1
106750-02 Warning & Rating Plate 1
