10
DVH943
English
●
CTR WIDTH (0 to 7):
Selecting CTR WIDTH mode will adjust the
localization of the centre channel between
the centre speaker and the front speaker L/R.
Distributing the centre channel sound to the
right and left will increase the integrated
sound field image, providing you with an
natural spatial feeling of sound.
Setting to the value 0 will produce the centre
sound with the centre speaker.
Setting to the value 7 will distribute the centre
sound to the front speaker L/R as the existing
stereo sound does.
• The initial value is [3].
5. Turn the [ROTARY] knob clockwise or
counterclockwise to adjust the value.
6. Press the [ADJ] button to return to the
original mode.
Setting Auto Volume
1. Press and hold the [ADJ] button for 1 second
or longer and enter adjust mode.
2. Press the [ a ] or [ d ] button to select the
[CALIBRATE E ].
3. Press the [ENT] button and [START E ] is
displayed.
4. Keep driving speed 50km/h and press the
[ENT] button.
5. “CALIBRATION” is flash for 2 seconds in
display.
6. If calibration is successful display indicate
“SUCCESSFUL” and sound long beep, or if
calibration is not successful display indicate
“FAILED” and sound 2 times a short beep.
7. If you failed, repeat steps 3 to 6.
Note:
• When installing this device or transferring it into
another vehicle, for sake of safety, always have
this work done by the store of purchase or your
nearest Clarion dealer. Installation requires
specialized techniques and experience.
Setting Auto Volume
sensitivity
1. Press and hold the [ADJ] button for 1 second
or longer and enter adjust mode.
2. Press the [ a ] or [ d ] button to select the [A-
VOL SENS]
3. Turn the [ROTARY] knob clockwise or
counterclockwise to make the adjustment.
The adjustment steps are below 6 steps, Off
➜
Low
➜
M-L
➜
Mid
➜
M-H
➜
High.
Setting Acoustic Features
3. Turn the [ROTARY] knob clockwise or
counterclockwise to select the value from
[MAX], [STD] or [MIN].
• The initial value is [MAX].
• MAX: maximum dynamic range mode of
the original source
• STD: recommended mode for standard
listening
• MIN: the most compressed dynamic range
mode that renders even low sounds easy
to hear.
4. Press the [ADJ] button to return to the
original mode.
MUSIC Mode Fine
Adjustments (PL II CONT)
When MUSIC Mode has been selected on the
PL II menu, finer adjustments can be made when
desired.
CTR WIDTH is not available when centre
speaker is turned off in the section “Turning
speakers on or off (SP-SEL)”.
1. Press and hold the [ADJ] button for 1 second
or longer to enter adjust mode.
2. Press the [ a ] or [ d ] button to show the [PL
II CONT E ] display.
3. Press the [ENT] button to display the
adjustment item.
4. Press the [ a ] or [ d ] button to select the
item.
●
PANORAMA (Y or N):
Selecting PANORAMA mode will extend the
front sound field image to the rear. If
surround effect does not seem to be
presented sufficiently, select the setting
position [Y].
• The initial setting is [N].
●
DIMENSION (0 to 6):
Selecting DIMENSION mode will shift the
sound field image to the front or the rear. If
the balance of the sound field image is too
much pulled towards the front or rear, the
balance front/rear can be corrected.
The adjusting value 3 is the centre position.
The range of 3 to 0 shifts the balance front/
rear to the rear. The range of 3 to 6 shifts the
balance front/rear to the front.
• The initial value is [3].
