Figure 7
NOTE: Any reference in this manual to the RIGHT or LEFT side of the tractor is observed from operator’s position.
NOTE: Hood styles vary by model.
NOTE: *Tractors vary by model and are equipped with either a PTO lever or a PTO knob, NEVER both.
A Systems Indicator Monitor/Hour Meter G Throttle Lever
B* PTO (Blade Engage) Lever H Cruise Control Button
PTO (Blade Engage) Knob I Ignition Switch Module
C Choke Knob J Brake Pedal
D Parking Brake Button K Drive Pedal
E Shift Lever L Deck Lift Lever
F Cup Holder M Seat Adjustment Lever
I
G
A
D
H
E
F
L
K
J
M
P
1/10
P
+
C
NOTE: Steering Wheel not shown for clarity.
B*
B*
