Cub Cadet GT-3235 User Manual
Page 9
9
SECTION 6: CONTROLS
Figure 3
A
B
C
D
E
F
G
H
I
K
L
M
N
O
P
Q
Parking Brake Lever
PTO Switch
Brake Pedal
Reverse Pedal
Forward Pedal
Center Lift Height Indicator
Ignition/Light Switch
Transmission Release Rod
Transmission Oil Fill/Dipstick
Cup Holder
Hydraulic Lift Lever
Steering Wheel Tilt Lock
Cruise Control Lever
Choke Lever
Throttle Lever
Seat Adjustment Lever (Not Shown)
* Steering Wheel and Seat
A
B
C
D
E
G
F
H
I
J
K
L
M
N
O
P
Q
R
(Not Shown)
T
Differential Lock Pedal
Deck Height Adjustment Knob
R
S
Removed For Clarity
Fuel Fill Cap
J
Indicator Light Pod
T
S
