19
8
Parts List
To order replacement
parts, call the Customer
Dealer Referral Line at
1-877-282-8684,
or visit
www.cubcadet.com to
find the nearest Cub
Cadet service dealer in
your area.
G E
N U I N E
FA
CTO
RY PAR
TS
Ref. Part Number Description
1 731-1901A Trail Shield
2 732-0842 Trail Shield Wire
3 736-0264 Flat Washer.330 ID x.630 OD
4 714-0104 Cotter Pin
5 732-0306 Compression Spring
6 734-2010 Wheel 9 x 2
7 712-0414 Top Lock Tab Weld Nut 1/4-20
8 16855 Ratchet Pawl Plate
9 10622B Plastic Spring Ratchet
10 748-0381 Pawl RH
748-0188B Pawl LH
11 738-0137A Shoulder Screw.340 ID x.285 OD
12 748-0318 Wheel Ratchet
13 736-0270 Bell Washer.265 ID x.75 OD
14 710-0751 Hex Cap Screw 1/4-20 x.620
15 737-3000 Grease Fitting
16 736-0931 Flat Washer.203 ID x.403 OD
17 747-0924 Wheel Pin Lock
18 682-9020A Caster Assembly RH
682-9021A Caster Assembly LH
19 682-9024 Caster Bracket Assembly RH
682-9026 Caster Bracket Assembly LH
20 720-0223 Grip
21 732-0803A Spring Lever
22 738-0529 Shoulder Nut.825 x .165 Lg.
23 736-0369 Flat Washer .508 ID x 1.0 OD
24 782-0566B Pivot Arm Assembly
25 750-0515 Spacer .510 ID x .70 OD
26 741-0978 Sleeve Bearing .504 ID x .830 OD
27 750-1056 Shoulder Spacer
28 710-0653 Tap Screw 1/4-20 x .375
Ref. Part Number Description
29 682-7528 Chain Cover Assembly
30 741-0324A Flange Bearing .506 ID x .590 Lg
31 682-7526 Transmission Axle Assembly
32 618-0263A Transmission Assembly Complete
33 710-0604A Hex Screw 5/16-18
34 713-0453 Chain
35 638-0012 Rear Axle Assembly
36 741-0522 Flange Bearing .506 ID x .715 Lg
37 732-0832 Torsion Spring
38 750-0151 Spacer .550 ID x .750 OD
39 710-1315 Screw 3/8-16 x .25
40 711-0835 Clevis Pin .50 Dia x 4.82 Lg.
41 750-0807 Spacer .385 ID x .624 OD
42 782-0568 Spring Bracket: Height Adjustment
43 710-1652 Screw 1/4-14 x .825
44 714-0474 Cotter Pin
45 682-3053 Handle Bracket Assembly - LH
46 682-3052 Handle Bracket Assembly - RH
47 725-0157 Cable Tie
48 710-1348 Screw 1/4-14 x.500
49 710-0260A Carriage Bolt 5/16-18 x.62
50 711-1146 Caster Axle
51 712-0397 Wing Nut
52 712-04063 Flange Lock Nut 5/16-18
53 726-0214 Push Cap
54 736-0232 Wave Washer.531 ID x.781 OD
55 736-0366 Flat Washer.640 ID x 1.12 OD
56 741-0685 Flange Bearing
57 734-1857 Wheel 7 x 2
58 731-1888 Hubcap - Spoke w/ Hole
59 731-0982A Hubcap - Radial Spoke
