DVR User Manual
57
Click the
icon beside the screen display mode,
channel select dialog will appear as below:
Take 8-channel view for example: user can checkmark 8
channels form 1-ch to 16-ch at random to display the live
pictures, A maximum of 16 channels can be selected.
Then click OK button to confirm the setting.
Fig 7-3 Channel Selection
Snap pictures
The system will automatically capture pictures and save those pictures in the computer by clicking
“Snap”
icon,
User should set up the path for those picture in the ConfigurationLocal configuration.
Color adjustment:
Drag the slide bar to adjust Brightness, Contrast, Hue, and Saturation. Click Default to reset them to original value.
Buttons
Description
Drag the scroll bar to adjust the brightness of channel
Drag the scroll bar to adjust the contrast of channel
Drag the scroll bar to adjust the saturation of channel
Drag the scroll bar to adjust the hue of channel
Click this button to recover the default value of brightness,
contrast, saturation and hue.
Save the adjustment
PTZ control
Please connect speed dome to the device via RS485 firstly. Make sure the protocol of the speed dome is supported by the
device and is configured accordingly in the DVR. User can move the dome up, down, right, left and adjust rotation speed, Iris
