1. EXPOSURE
EXPOSURE MENU NORMAL / BLC / WDR / HLI
SENSE UP OFF / X2~X1024
AGC OFF / LOW / MIDDLE / HIGH
LENS ELECTR / DC IRIS
BRIGHTNESS 0~99
EXIT
Exposure Settings :
Normal
To be used under normal light
conditions ,where none of the
conditions listed below are present
.
BLC ( Backlight Compensation)
WDR (Wide Dynamic Range)
This Function is used to Sense up: (Slowshutter Speed)
OFF
X2~X1024 Manual Slowshutter
mode select from low x2 up to high
x1024
AGC :( Increases Brightness , the
higher the setting the more noise
will get on the video)
Lens:
ELECTR.( you must use this option
as default setting)
Go to Submenu and select the
speed for the Shutter.
‐ 1/100000 to 1/60FLC
‐ AUTO
‐ X2 to X1024
DC IRIS
1/100000 1/60FLC
Brightness:
Brightness control
it ranges from 0~99
2. COLOR
WB MODE ATW/ AWC / MANUAL / PUSH
EXIT
compensate the strong Backlight
conditions.
HLI (High Level Interface)
This Function is used when reading
License plate at night.
ATW ( Auto Tracking White Balance)
It Automatically adjusts the color between
1.800K and 10500K.
Use this option if the lighting conditions
changes constantly
MANUAL(Adjust the color manually)
Adjust the RED and BLUE settings with values
ranging from 0~255
OFF AGC disabled
LOW Low AGC Setting
MIDDLE Middle AGC Setting
HIGH High AGC Setting
‐ 1/100000 to 1/60FLC
‐ AUTO
‐ X2 to X1024
AWC ( Preset White Balance)
Use this option when many white objects
appears on the scene and also when a object
merges to the scene with similar color shade
PUSH
Adjust the white balance by focusing at a
white object or white sheet of paper and
press enter to adjust the color.
