Page 5: Dipswitches settings

Text mode
Original mode

7. COMM

PROTOCOL

P/D

CAMERA ID

ID DISPLAY

OFF/ON

ZONE LABEL

ON/OFF

ZONE LABEL UP/DN

CHAR SELECT

VERSION

VER 1.1

LE/RI

POSITION

INITIAL

RETURN

8 RESET

PROTOCOL P/D

CAMERA ID ‐ 000

ID DISPLAY (ON/OFF)

ZONE LABEL (ON/OFF) set the camera label and location of the label on the screen

VERSION‐ (N/A)

8. RESET

OFF STATE

Dipswitches Settings

For License plate Camera Mode: Dipswitch #10 ‐ ON

Also Adjust the Dipswitches for LUX Sensitivity

For High Resolution Camera Mode: Dipswitch#10 ‐ OFF

1 LUX

1,2 OFF

When Set to License Plate Mode, please select the Shutter Speed in the OSD Menu

2 LUX

1 OFF 2 ON

4 LUX

1 ON 2 OFF

1/50 sec

20mph

30kph

10 LUX

1,2 ON

1/100 sec

30mph

45kph

1/250 sec

40mph

60kph

The IR LED will turn on depending on the LUX setting

1/500 sec

50mph

80kph

1/1000 sec

75mph

120kph

1/2000 sec

90mph

150kph

1/4000 sec

110mph

180kph

1/10000 sec

135mph

220kph
