Transmitter to receiver placement
If radios are installed either indoors or outdoors at distances closer than recommended, antennas can overpower each other and cause
undesired effects. If testing radios within one or two feet, remove both antennas. The radios will still be able to signal each other at
close distances. This applies to both indoor and outdoor units.
Antennae
Estimated Ethernet
Throughput
Range Maximum
Line-of-Sight
Maximum
Non-Line-of-Sight
Minimum Recommended
Distance from paired
antenna
AW2-900
935 kbps
1 mile
5 walls/450 FT
10 FT
AW5-900
935 kbps
2 miles
6 walls/500 FT
10 FT
AW11-900
935 kbps
20 miles
1,200 FT w/ trees
125 FT
AW15-900
935 kbps
40 miles
1,500 FT w/trees
150 FT
AW2-2400
935 kbps
0.5 miles
N/A
10 FT
AW19-2400
935 kbps
20 miles
N/A
10 FT
Antennae
Estimated Rate
Point-to-Point
Access Point to Sub-
scriber (PTMP)
Minimum Recommended
Distance from paired
antenna
AW58100 Series
5
50 miles
10 miles
150 FT
25
30 miles
5 miles
150 FT
75
10 miles
2 miles
150 FT
100
4 miles
0.75 miles
150 FT
AW58300 Series
15
40 miles
8 miles
150 FT
75
20 miles
4 miles
150 FT
225
6 miles
1 miles
150 FT
300
2 miles
0.5 miles
150 FT
AW58800 Series
40
25 miles
6 miles
150 FT
200
8 miles
1.5 miles
150 FT
540
1 mile
1,000 feet
150 FT
800
2,000 feet
500 feet
150 FT
