Ashdown LITTLE GIANT 1000 - Manual (Page 6)

Specifications
INPUTS
Passive Input
Impedance - 1M Ohms Level 150mV to 10V p-p
Active Input Impedance - 10K Ohms Level 300mV to 20V p-p
Effects Return Impedance - 10K Ohms Input Level 0dBu Nominal
Line In Impedance - 10K Ohms Input Level 0dBu Nominal
OUTPUTS
Line Out
Impedance - 1K Ohms Level 0dBu Nominal
Effects Send Impedance - 1K Ohms Level 0dBu Nominal
D.I.Output 600 Ohms Balanced Level -20dBu Nominal
Speaker Outputs 350 Watt Combined Minimum Impedance 4 Ohms
Output Power 350W RMS into 4 Ohms
1000 Watt 4 Ohms for each socket
Output Power 2 x 500W RMS into 4 Ohms
Frequency response -3dB @ 25Hz and 25kHz
EQUALISATION
Bass
+/- 15dB - 100Hz Shelving
Lo-Mid +/- 15dB - Frequency 180Hz to 1.6kHz Q = 1 Octave
Hi-Mid +/- 15dB - Frequency 750Hz to 7.5kHz Q = 1 Octave
Treble +/- 15dB - Frequency 3.5kHz to 10kHz Shelving
DEEP + 15dB @ 50Hz
SHAPE + 8dB @ 30Hz & 10kHz -12dB @ 400Hz
Signal to Noise Better than 80dB (EQ Flat)
Distortion Less than 0.5% THD
