Ashdown FREEBASS - Manual (Page 9)

Specifications
TRANSMITTER
Oscillation Mode
PLL UHF Synthesized
Carrier Frequency UHF 470-900MHz Dependent on applicable country regulations
Frequency Response 50Hz-15kHz +/-3dB
Frequency Stability +/-0.005% (-10 to 50 degrees C)
THD 1kHz<0.8%
Modulation Mode FM (F3E)
RF Output Power 5-50mW adjustable 3 bands
Dynamic >100dB
Tone Frequency 30-33kHz
Max Deviation +/-35kHz
Battery AA Type x 2
Current Drain 100mA
Weight 0.082Kg
RECEIVER
Channel
Up to 100 pre-set channels for each frequency band
Frequency Band UHF 470-900MHz Dependent on applicable country regulations
Receiver Type PLL UHF Synthesized
Frequency Response 50Hz-15kHz +/-3dB
Frequency Stability +/-0.005% (-10 to 50 degrees C)
THD 1kHz<0.8%
Modulation Mode FM (F3E)
S/N Ratio >90dB
Dynamic >100dB
RF Sensitivity -100dBm/30dB SINAD
Audio Output Unbalanced Jack 550mV
Balanced XLR 1.1v
Power Supply DC 15v 500mA AC adaptor
Dimensions 217(W) 122(D) 44(H)mm
8.2” x 6.1” x 1.7”
Weight 0.385Kg
