MiBass Interface-Features
• High-resolution 48kHz converters for high-end audio
quality
• Works with your PC or Mac–no setup or drivers re-
quired.
• Powered via USB bus–no external power supply need-
ed but can be used with a 9v supply or 9v battery.
• Stereo headphone output with dedicated level control
lets you monitor both input and output.
Its inputs and outputs give you total connecting flexibility
to mixers, loudspeakers or headphones. The illuminated
Ashdown VU meter gives you an indication that the unit is
powered and also enables you to set the level of your bass.
The Di Output enables you to use your Ashdown App in
conjunction with the MiBass interface allowing you to plug
straight into a PA system or recording desk using the sounds
produced by the App (Only available on iPhone® or iPadd®)
• Bass input
• Passive and Actice Hi/Lo Pad
• A 3 band 3.5mm input jack allows you connect with
iPod®/iPhone®/iPad®
All Trademarks mentioned belong to their respective owners and are not affiliated with
Ashdown Design & Marketing®
System Requirements/Specifications
The MiBass is PC and Mac-compatible. Therefore, no in-
stallation procedure or drivers are required for the correct
functioning of the MiBass.To work with the MiBass, your
computer must fulfill the following minimum requirements:
• PC Intel® or AMD® CPU, 400MHz or higher Minimum
128MB RAM USB 1.1 interface Windows® 2000, XP.
• MAC® G3, 300MHz or higher Minimum 128MB RAM
USB 1.1 interface MAC OS® 9.0.4 or higher, 10.X or
higher.
Instrument (Bass) IN
Connectors Standard 1/4” jack
Input impedance approx. 470 kΩ
input level 150mV /300mV(Active)
iPhone IN/OUT
4 poles 3.5mm headphones jack
Input impedance approx. 10 kΩ
input level 120mV
output impedance approx. 4.7 kΩ
output level 10mV
LINE OUT
Connectors XLR, balanced
Output impedance approx. 680 Ω
output level 25mV
PHONES OUT
4 poles 3.5mm headphones jack
Output impedance approx. 5 Ω
output level 600mV
DIGITAL PROCESSING
Converter 16-bit converter
Sampling rate 32kHz, 44.1kHz, 48kHz
SYSTEM DATA
Frequency response
10 Hz to 20 kHz, ± 1 dB @ 44.1 kHz sample rate
10 Hz to 22 kHz, ± 1 dB @ 48.0 kHz sample rate
THD 0.1% typ. @ -10 dBu, 1kHz
Crosstalk -65 dB @ 0 dBu, 1 kHz
USB 2.0
Connectors type A (Cable included)
POWER SUPPLY
USB connection 5V, 200mA max.
9V 6F22
Technical specifications and appearance subject to change without notice. The information
contained herein is correct at the time of printing.
