AAA
FRONT PANEL
APPTEK
This enables you to further expand your amp for use with the provided cable and your Agile Partners Amp Kit App. The App
features the Ashdown ABM 900 and ABM 810 cab which can be used with your amp utilizing the features of the ABM including
SUB Harmonics, Valve Drive, Compression and EQ.
HEADPHONES
A headphone jack socket is provided to allow stereo headphones to be plugged into the amplifier for silent practice. This cuts
out the main speaker when a jack plug is inserted.
LINE IN
A single balanced line input is provided for play along practice. Used in conjunction with the Headphones socket for silent
practice. Also see, MIX.
AUX MIX
Set the level of your Backing Track by using the ‘MIX’ Rotary control provided.
MASTER LEVEL
Use the output level control to adjust the playing volume of the amplifier.
E.Q.
This passive EQ has bass, middle and treble tone controls.
DI (were applicable)
DI Output provides a balanced post signal output.
DRIVE (were applicable)
This adds tube emulated overdrive as a tube amp would when adding gain. From slight grit to full on overdrive.
INPUT
Two input jack socket are provided for your instrument. There is a high impedance input designed to have sufficient headroom
available to allow active basses to be used. There is also a low impedance input perfectly match the impedance of the pick-ups
on a passive bass. Use the input gain control to adjust for the sensitivity of your instrument.
Ashdown Amplifiers reserve the right to change specifications without notice. E & O E. All contents © Ashdown 2014.
AFTER 8 Front Panel
PERFECT 10 Front Panel
Back Panel
Specifica
tion
S
AFTER 8
Output Power
20watts RMS into 8 ohms
Input Impedance 1 Meg ohm
Input Signal Range 100Mv to 10v
E.Q. Passive Bass, Middle, Treble.
PERFECT 10
Output Power
40watts RMS into 8 ohms
Input Impedance 1 Meg ohm
Input Signal Range 100Mv to 10v
E.Q. Passive Bass, Middle, Treble.
VINTAGE 12 Front Panel
AFTER 8
INPUT
hIGh INPUT LoW MIDDLE AUX MIX TREBLE VoLUME LINE IN BASS
CLIP APPTEk
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
DRIVE
DI PERFECT 10
INPUT
hIGh INPUT LoW MIDDLE AUX MIX TREBLE VoLUME LINE IN BASS
CLIP APPTEk
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
DRIVE
DI VINTAGE 12
INPUT
hIGh INPUT LoW MIDDLE AUX MIX TREBLE VoLUME LINE IN BASS
CLIP APPTEk
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
Drive in/out
FIVE 15 & FIVE 15 BB Front Panel
FX LooP
SEND RETURN
DRIVE DI
FIVE 15
INPUT
hIGh INPUT LoW MIDDLE AUX MIX TREBLE VoLUME LINE IN BASS
CLIP APPTEk
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
0
3
10
7
1
2
46
8
9
Drive in/out
FIVE 15 BB
VINTAGE 12
Output Power
20watts RMS into 8 ohms
Input Impedance 1 Meg ohm
Input Signal Range 100Mv to 10v
E.Q. Passive Bass, Middle, Treble.
FIVE 15 & BB
Output Power
100(220BB)watts RMS 8 ohms
Input Impedance 1 Meg ohm
Input Signal Range 100Mv to 10v
E.Q. Passive Bass, Middle, Treble.
REAR PANEL
FUSED MAINS INLET SOCKET
This is for connection of the unit to your countries mains power supply. Please
ensure that the type and rating of mains fuse marked on the rear panel is used when
this is replaced.
POWER SWITCH
The power to the unit is turned on with the rear panel power switch. A power led on
the front panel will light to indicate that the amplifier is switched on.
SPEAKER OUT
There is a speaker out fitted to the After 8, Vintage 12 and Five 15 BB with an 8Ohm
min load.
