acidlab Autobot User Manual
Page 13
13
Zustand LED
buttom
- Octave
+ Octave
Octave-Offset
Octave +
off
flashes
+ 2 Octaves
Octave +
off
constant on
+ 1 Octave
---
off
off
----
Octave -
constant on
off
- 1 Octave
Octave -
flashes
off
- 2 Octaves
As described in the table, it is possible to shift the pitch of each note with the buttoms
Octave Up/Down between the 5 octaves. Without the Octave Up/Down buttons it is
always programmed in the middle octave (no LED lights).
Programming Pattern Length (Pattern Write Tap Mode)
When you press the buttom Lenght, the LEDs 1-8 of the row light. Now you can
select the last step 1-8, and the pattern length of your active pattern. You press one
buttom 1-8 of the keyboard, and this step is selected as the last step of the pattern.
E.g. step 3. Now the Pattern repeats after the third step, and is 3 steps long. Press
the buttom Length twice, and the LEDs 9-16 lights. Now you can select the pattern
length between 9-16. The programmed pattern length is transferred to the other
modes. The not played steps stay in the memory.
