4
Controls
Tune:
This sets the VCO frequency tuning.
Waveform:
This is to switch the waveform for the VCO output.
Select between SAW and the 303-Square.
VCO Mod:
This sets the amount of the input signal from the VCO CV In.
The input signal modulates (linear) the frequency of the VCO.
VCF Mod:
This sets the amount of the input signal from the VCF CV In.
The input signal modulates the cutoff-frequency of the VCF.
The input will work for low audio signals, too.
Cutoff:
This sets the cutoff-frequency of the filter.
Resonance:
This sets the resonance of the filter and will lower the volume with increase
resonance, too.
Env Mod:
This sets the amount of the envelope to the VCF.
Decay:
This sets the decay-time of the VCF envelope.
Gate/VCA:
The Gate/VCA switch changes the VCA envelope.
Select ´Gate´ for the original gated envelope. Select ´VCA´ for the non-gated
envelope.
Accent:
Accent controls the amount of the accent envelope to the VCF and VCA.
The Accent In needs a 5-12 Volt signal to control the accent-length and will give an
increase in volume, shorten the decay of the filter envelope.
Volume:
This controls the volume of the audio output.
