CV In
The CV In converts 1V/octave to the pitch.
Gate In
The Gate In needs a 5-12 Volt signal to controll the note-length.
Accent In
The Accent In needs a 5-12 Volt signal to controll the accent-length.
The Accent In is normally controlled with the Accent Out of a Bassline, to play its
lines, with the extended sound variations of the Bombass.
Outputs
Audio Outputs:
Output is the main output (6,3 mm of mono), to connect a mixer. Headphones is a
headphone output (3.5 mm stereo).
Both Outputs are controlled with volume.
The produced bass frequencies are a large load for following amplifiers and
loudspeakers.
Without protection they can take damage!
