RENEWAL PARTS IDENTIFICATION
Fuses — 600 Volt Fuseholders
Manufacturer’s
Part Number Amps
Cat. No.
Use Part Number Description
128-026510-001 35 JKS 35
128-026510-004 40 JKS 40
Power 129-025643-001 600 Volt, 60 Amp, 3 Pole
128-026510-005 45 JKS 45
128-026510-006 50 JKS 50
128-027590-001 1 KTK-R-1
Control/
129-048473-001 2, 3, 4, 5 poles contact section
128-027590-008 8 KTK-R-8
Motor
129-048475-001
End barrier section for use
128-027590-010 15 KTK-R-15 with 129-048473-001
Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112-027567-001
Fan Delay . . . . . . . . . . . . . . . . . . . . . . . . . . 300-048038-001
Cutout . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300-049602-008
Manual Reset Cutout (Optional) . . . . . . . . . 300-117647-006
Grille . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134-119147-003
Louver Assembly . . . . . . . . . . . . . . . . . . . . 182-047073-003
Mounting Bracket - (Right Hand) . . . . . . . . 027-025836-001
(Left Hand) . . . . . . . . . 027-025836-002
Thermostat (Optional) . . . . . . . . . . . . . . . . 300-026604-001
Contactor . . . . . . . . . . . . . . . . . . . . . . . . . . 072-304551-008
Auxiliary Contact . . . . . . . . . . . . . . . . . . . . 072-304551-101 16
11
12
13
10
14
15
9
8
7
3 MOTORS AND CAPACITORS
6 FUSES
2
Voltages
Size Part Number V.A. Rating
Primary Secondary
Large
315-052169-011
970
220, 230, 240, 440, 460, 480 110, 115, 120
315-052169-012 550, 575, 600 110, 115, 120
Small
315-304252-001
40
240 & 480 120
315-304252-003 575 120
TRANSFORMERS 5 4
5
4
PARTS COMMON TO ALL HEATERS
Motors Capacitors
Manufacturer’s
Specifications
Manufacturer’s
Specifications
Part No.
Cat. No. Volts Amps Phase Cycles RPM HP
Part No.
Cat. No. Type Vac Cap.
193-025776-001 HF2K007N 115 5.4 1 60 1625 1/3 040-025779-001 1270 Oil 370 5 MFD
193-025776-002 HF2K006N 230 2.54 1 60 1625 1/3 040-025779-002 1271 Oil 370 6 MFD
193-302120-011 P55YYBYV-887 460 0.9 3 60 1725 1/3 — — — — —
2 3
