Craftsman 486.24539 - Manual (Page 5)

13
11 12 16
5
3
1
5
16
12
11
13
15
15
6
7
7
9
a
b
b
a
2
8
8
4
10
4
14 15
15
15
15
6
9
PARTS BREAKDOWN
1
2
3
4
5
6
7
8 49574
25505
25506
24192
49575
49576
44292
43224
R19172410
Striper Tube
Scraper Bar
Axle
Hitch Bracket
End Cap
Hitch Tube
Bolt, Hex 5/16" x 2-1/2"
Bolt, Hex 5/16" x 2-1/4" 1
1
1
2
2
2
2
2
# PART # DESCRIPTION QTY
9
10
11
12
13
14
15
16
43084
47623
47963
44166
43343
47810
741-0248
Bolt, Hex 5/16" x 1-3/4"
Pin, Hitch
Hex Flange Bearing
Washer, 0.53 x 1.5"
1/2" Palnut
Pin, Hairpin Cotter
Nut, Hex 5/16" Nylock
Round Flange Bearing 2
1
2
2
2
1
6
2
# PART # DESCRIPTION QTY
5
REPAIR PARTS FOR MODEL 486.24539
