POWEBSOURCE
■ Battery Operation
1. Open the Battery Compartment cover as shown in the
figure.
2. Insert 6 UM*1 size (Panasonic R20/LR20 or equivalent)
batteries into the Battery Compartment, making sure that
the proper polarities are maintained, and that the
batteries are installed in the specified numerical order.
Low.rShen 0 r^r^n3 0
Upper Sh»lt 0 ^
6 ^ 5 ^ 4
©
3. Replace the compartment cover.
Notes;
•Batteries installed with incorrect polarities may leak
and damage this unit
•Do not mix batteries (old and new) or types (carbon
and alkaline).
•Battery removal
Remove as shown in the figure below.
Upper Shelf
PUSH UP
Lower Shelf
?
To Prevent Possible Damage to This Unit
•Load new batteries with their polarities (@ and ©)
aligned correctly.
•Do not apply heat to batteries, or internal short-
circuit may occur.
•If this unit is not to be used for a long period of time,
or used on AC power source, remove all batteries
and store them in a cool and dry place.
•Remove spent batteries immediately and dispose
of them.
•Do not use old and new batteries together. Also
never use an alkaline battery with a manganese
battery.
•Battery life
When the batteries are weak, the tape speed will slow down,
the sound will become distorted, and the volume will
decrease.
if the set is not used for a long period of time or is
used only from an AC power source, remove all the
batteries to prevent potential damage due to possible
battery leakage.
■ AC Power Operation
Connect the included AC power cord to the AC Socket in the
unit and your household AC power outlet.
ACIN-
AC power cord AC power outlet
AC 240 V
Note:
To operate on battery power, unplug the AC power
cord from the household AC power outlet and the AC
Socket on the unit.
-3 -
