Panasonic RQ-SW09V - Manual (Page 3)

RADIO
To obtain better reception
FM;
Extend the
headphone cord.
FM RECEPTION
NORMALI I CITY
ЩЩ]
AM:
How to receive an FM broadcast clearly
Set [FM RECEPTION) to INORMAL).
When the FM reception is impaired, or there
is interference Irom a powerful station, set it
to [CITY].
When a station is tuned in
FM
Preset tuning
Frequencies of up to 20 radio stations (10
each for AM and FM) can be stored in the
memory,
■ Memory presetting
(Available only from the main unit)
1. Tune in the station to be stored.
2. Set [MAIN, SUB, HOLD] to ISUB],
3. Press and hold one of the memory
buttons ([1], [21, [3], (41, [51) for about
2 seconds.
To select a memory channel from 6 to 10
1. Press [ВАТТ CHECK+5].
Г
' + 5
3 beeps can be heard.
Memory
channel
2. Within 10 seconds press and hold one of
the memory buttons for about 2 seconds.
For example (Memory channel 7):
[ВАТТ CHECK+51-*[2l
■ To recall a preset station
(From the main unit)
1. Set[MAIN, SUB, HOLD)to[SUB].
2. Press a memory button.
To select a memory channel from 6 lo
10, press [ВАТТ CHECK +5) and within
10 seconds press a memory button.
•Release the memory button within 2
seconds.
(From the remote control)
During reception, press [+1 or [-].
Note:
Pressing [ВАТТ CHECK +5) while 45" is
displayed clears it.
When using overseas
Allocations need to be changed according to
the area.
Every time the following procedure is per­
formed, the allocation setting changes as
follows:
FM 0.2 MHz. AM10kHz<—
(original setting)
i
FM 0.1 MHz, AM 10 kHz
i
FM 0.05 MHz. AM 9 kHz—
■ How to adjust the allocation
settings
(Available only from the main unit)
While playing the radio
1. Set [MAIN, SUB, HOLD] to [MAIN).
2, While pressing [BAIT CHECK +5),
press and hold (5, RADIO ON/BAND) tor
about 3 seconds.
•The changed allocation settings (FM and
then AM) are displayed.
Note;
Converting the allocation erases the stations
previously stored in тегтюгу.
BATTERY
CAUTION
MAINTENANCE
•Align the poles (@ and 0) properly when
inserting the batteries.
•Do not recharge ordinary dry cell batteries.
•Remove the batteries if the unit is not to be
used for a long time.
•Do not use the batteries if the covering has
been peeled off.
Mishandling of batteries can cause elec­
trolyte leakage which can damage items the
fluid contacts and may cause a fire.
If electrolyte leaks from the batteries, con­
sult your dealer.
Wash thoroughly with water if electrolyte
comes in contact with any part of your body.
•If rechargeable batteries are to be used,
rechargeable batteries manufactured by
Panasonic are recommended.
Battery condition indicator
The indicator is shown whenever the radio
is on or a tape is traveling. When the battery Is weak
The indicator will flash and then:
I
•When you start a tape or radio reception,
the indicator scrolls 2 times before it lights,
j •When you press (ВАТТ CHECK +5] in the
stop mode, the indicator scrolls 2 times
and lights lor about 5 seconds.
•The indicator may show a lower amount of
charge during some operations.
•Leaving the unit in this condition erases
the contents of the memory.
Replacing the batteries within 30 seconds
will retain any stored information.
•Avoid using or placing this unit near
sources of heat. Do not leave it in an auto­
mobile exposed to direct sunlight for a long
period of time with doors and windows
closed.
•To avoid product damage, do not expose
this product to rain, water or other liquids.
Caution when using the Included head­
phones
•Do not allow children or people who are
unwell or not in full control of their faculties
to wear these headphones.
• If you feel nauseous while using the head­
phones, discontinue use immediately.
Listening caution
Do not play your headphones or earphones
at a high volume. Hearing experts adwse
against continuous extended play.
If you experience a ringing in your ears, re­
duce volume or discontinue use.
Do not use while operating a motorized ve­
hicle. It may create a traffic hazard and is il­
legal in many areas.
You should use extreme caution or tem­
porarily discontinue use in potentially haz­
ardous situations.
Even if your headphones or earphones are
the open-air type designed to let you hear
outside sounds, don't turn up the volume so
high that you can’t hear what’s around you.
Sound can be deceiving. Over time your
hearing "comfort level" adapts to higher vol­
umes of sound. So what sounds "normal"
can actually be loud and harmful to your
hearing.
Guard against this by setting your equip­
ment at a safe level BEFORE your hearing
adapts.
To establish a safe level:
•Start your volume control at a low setting.
•Slowly increase the sound until you can
hear it comfortably and clearly, and without
distortion.
Once you have established a comfortable
sound level:
•Set the dial and leave it there.
If the surfaces are dirty
To clean this unit, wipe with a soft, dry
cloth.
If the surfaces are extremely dirty, use a soft
cloth dipped in a soap-and-water solution or
a weak detergent solution.
•Never use alcohol, paint thinner or benzine
to clean this unit.
•Before using chemically treated cloth, read
the instmctions that came with the cloth
carefully.
For a cleaner crisper sound
Clean the heads regularly to assure good
quality playback.
Use a cleaning lape(nol included).
