CONNECTIONS
[Terminal]
(-VIDEO-,
IN
OUT 75 ii-
[Signal level and Terminal Impedance]
“HIZ
Item
Te rm i n
Level
Impedance
Remarks
O
m
Q
INPUT
1 Vp-p
75ii /HIZ
Video Signal
includes
>
OUTPUT
1 Vp-p
75fi /HIZ
Sync Signal
(Positive)
[Connector]
Video Input/Output: BNC-type connectors
[Application with other equipment]
Terminal
Signal
Equipment
Remarks
INPUT
Input Signal
from other
equipment
VTR/VCR
VHS VCR
Video
Camera
Input and output connectors are bridged
(parallel connected).
OUTPUT
Input
Signal
Monitor
or
VTR
When this connector is not used, then termi
nation select switch should be set to 7 5 p o
sition,
When
another
monitor's
input
is
connected to this monitor's output connec
tor, the termination select switch should
be set to HIZ position. The last monitor
in the series of monitors should then have
it's switch set to 75ii.
[75 ii - HIZ Switch]
- 6
-
