HOW TO PROPERLY ORDER PARTS
In addition to part description and part number, please give model number, serial number, and type of gas used.
MARCH 2009 Page 19
NA T .
M ODEL NUM BER L .P.
REF. PA RT LIST PA RT LIST PA RT LIST PA RT LIST
PA RT DESCRIPTION NO. NO. PRICE NO. PRICE NO. PRICE NO. PRICE
Cas ing Side, Right 1a 34065 62.40 $ 34065 62.40 $ 34560 68.30 $ 34560 68.30 $
Cas ing Side, Lef t 1b 34055 62.40 $ 34055 62.40 $ 34550 68.30 $ 34550 68.30 $
Center Front Panel A s s embly 1c 34104 31.00 $ 34104 31.00 $ 30534 32.00 $ 30534 32.00 $
Top A s s embly 1d 34050 11.80 $ 34050 11.80 $ 34050 11.80 $ 34050 11.80 $
Upper Bac k A s s embly 1e 34080 47.60 $ 34080 47.60 $ 34080 47.60 $ 34080 47.60 $
Low er Bac k A s s embly 1f 34090 40.70 $ 34090 40.70 $ 34575 44.90 $ 34575 44.90 $
Bottom A s s embly 1g 34070 17.90 $ 34070 17.90 $ 34070 17.90 $ 34070 17.90 $
Cas ing Mounting Brac kets N/A *30260 1.40 $ *30260 1.40 $ *30260 1.40 $ *30260 1.40 $
Liner A s s embly 2 34115 90.50 $ 34115 90.50 $ 34600 97.50 $ 34600 97.50 $
Fan Shroud A s s embly 3 34140 26.50 $ 34140 26.50 $ 34140 26.50 $ 34140 26.50 $
Top Louv er 4 34100 18.10 $ 34100 18.10 $ 34590 19.70 $ 34590 19.70 $
Bottom Louv er A s s embly 6 30100 35.20 $ 30100 35.20 $ 30100 35.20 $ 30100 35.20 $
Upper Front Shield 7 30250 3.90 $ 30250 3.90 $ 30250 3.90 $ 30250 3.90 $
Sw itc h Box 8 30252 8.00 $ 30252 8.00 $ 30450 8.10 $ 30450 8.10 $
Sw itc h Box Cov er 9 30253 3.10 $ 30253 3.10 $ 30253 3.10 $ 30253 3.10 $
Low er Front Shield 10 30256 5.70 $ 30256 5.70 $ 30256 5.70 $ 30256 5.70 $
Motor Mounting Brac ket 11 *34088 4.00 $ *34088 4.00 $ *34579 2.30 $ *34579 2.30 $
Burner 12 72107 42.50 $ 72107 42.50 $ 72107 42.50 $ 72107 42.50 $
Pilot Brac ket 53 34440 4.50 $ 34440 4.50 $ 34440 4.50 $ 34440 4.50 $
V alv e, 7200ER, Natu r al Gas 13 72090 153.50 $ N/A N/A N/A N/A 72090 153.50 $
V alv e, 7200ER, L.P. Gas 13 72091 153.50 $ N/A N/A N/A N/A 72091 153.50 $
V alv e, 7200IPER, Natur al Gas 13b N/A N/A 72092 143.60 $ 72092 143.60 $ N/A N/A
V alv e, 7200IPER, L .P. Gas 13b N/A N/A 72093 143.60 $ 72093 143.60 $ N/A N/A
Manif old 14 72103 21.30 $ 72103 21.30 $ 72103 21.30 $ 72103 21.30 $
Burner Orif ic e, Natur al Gas 15 72147 3.80 $ 72147 3.80 $ 72140 3.80 $ 72142 3.80 $
Burner Orif ic e, L.P. Gas 15 72149 3.80 $ 72149 3.80 $ 72141 3.80 $ 72143 3.80 $
Fan Motor 16 72108 82.30 $ 72108 82.30 $ 72110 93.40 $ 72110 93.40 $
Fan Blade 17 78101 26.90 $ 78101 26.90 $ 78101 26.90 $ 78101 26.90 $
Rubber Grommet 18 78010 3.40 $ 78010 3.40 $ 78010 3.40 $ 78010 3.40 $
Limit Sw itc h 60T11-L220F 19 N/A N/A N/A N/A 72160 6.60 $ 72160 6.60 $
Limit Sw itc h 60T11-L180F 19 78065 6.60 $ 78065 6.60 $ N/A N/A N/A N/A
Fan Sw itc h 60T12-120-15 Deg. F 20 78067 6.80 $ 78067 6.80 $ 78067 6.80 $ 78067 6.80 $
Speed Sw itc h 60T13-F160-30 21 N/A N/A N/A N/A 78066 9.90 $ 78066 9.90 $
A ux . Limit Sw itc h 60T15-L350 22 78086 10.40 $ 78086 10.40 $ 78086 10.40 $ 78086 10.40 $
Thermos tat 24 V olt 23 78355 22.30 $ 78355 22.30 $ 78355 22.30 $ 78355 22.30 $
Trans f ormer 24 78069 26.20 $ 78069 26.20 $ 78069 26.20 $ 78069 26.20 $
Trans f ormer Plate N/A 34089 4.20 $ 34089 4.20 $ 34089 4.20 $ 34089 4.20 $
Terminal Board 35 78300 5.60 $ 78300 5.60 $ 78300 5.60 $ 78300 5.60 $
Pilot 0.140.512, Natur al Gas 25 72020 25.20 $ N/A N/A N/A N/A 72020 25.20 $
Pilot 0.140.502, L .P. Gas 25 72021 25.20 $ N/A N/A N/A N/A 72021 25.20 $
Coz y Handle 26 84003 2.50 $ 84003 2.50 $ 84003 2.50 $ 84003 2.50 $
Thermos tat Wire 27 74518 1.50 $ 74518 1.50 $ 74518 1.50 $ 74518 1.50 $
Thermoc ouple Q309A 1954 28 78095 12.70 $ N/A N/A N/A N/A 78095 12.70 $
Ins ulated Staples 29 74209 1.40 $ 74209 1.40 $ 74209 1.40 $ 74209 1.40 $
Pilot 3S-24F, Natu r al Gas 25b N/A N/A 72098 41.60 $ 72098 41.60 $ N/A N/A
Pilot 3S-24F, L.P. Gas 25b N/A N/A 72097 37.50 $ 72097 37.50 $ N/A N/A
Wiring Harnes s 30 72251 20.90 $ 72251 20.90 $ 72250 23.50 $ 72250 23.50 $
Flame Sens or S-1 28b N/A N/A 72025 15.70 $ 72025 15.70 $ N/A N/A
DV C F653B-R
DV C F654B-R
DV C F403B-R
DV C F404B-R
PA RTS LIST CONTINUED
DV C F407B-R
DV C F408B-R
DV C F557B-R
DV C F558B-R
M r. Contra ctor, we only s ell parts through our wholes alers , but the pric es lis ted above are for y our c onvenienc e.
For prom pt parts s ervic e, c ontac t the wholes aler from whic h y ou purc has ed y our Coz y heater. NOTE : P arts &
s c hem atic drawings on c urrent m odels are s hown at w w w .coz yhe a te rs.com .
