MBX50 PNEUMATIC TIRE LIFT TRUCK SPECIFICATIONS
GENERAL G20T-16 G20HT-16 D20T-16
1 Power Type Gasoline Gasoline Diesel
2 Operation Type Sit-Down Sit-Down Sit-Down
3 Capacity @ 24 in. (600 mm) load center* lbs. (kg) 4,000 (1,810) 4,000 (1,810) 4,000 (1,810)
4 Load distance from center axle (2-stage) in. (mm) 17.9 (455) 17.9 (455) 17.9 (455)
5 Wheelbase in. (mm) 65 (1,650) 65 (1,650) 65 (1,650)
WEIGHT
6 Service weight (includes 2-stage std. mast & forks) lbs. (kg) 7,180 (3,255) 7,180 (3,255) 7,290 (3,310)
7 Axle Loading
Loaded Front lbs. (kg) 9,880 (4,480) 9,880 (4,480) 9,980 (4,485)
Rear lbs. (kg) 1,300 (590) 1,300 (590) 1,410 (640)
Unloaded Front lbs. (kg) 3,270 (1,485) 3,270 (1,485) 3,280 (1,490)
Rear lbs. (kg) 3,900 (1,770) 3,900 (1,770) 4,010 (1,820)
TIRE
8 Tire type Pneumatic Pneumatic Pneumatic
9 Tire size, front 7 - 12 - 12PR 7 - 12 - 12PR 7 - 12 - 12PR
10 Tire size, rear 6 - 9 - 10PR 6 - 9 - 10PR 6 - 9 - 10PR
11 Number of wheels, front / rear x=driven 2x / 2 2x / 2 2x / 2
12 Tread (center of tires)
Front in. (mm) 38 (966) 38 (966) 38 (966)
Rear in. (mm) 37.8 (960) 37.8 (960) 37.8 (960)
DIMENSIONS
13 Tilting angle, 2-stage (FV) masts, forward / backward deg. 6 / 12 6 / 12 6 / 12
14 Tilting angle, 3-stage (TFV) masts, forward / backward deg. 6 / 5 6 / 5 6 / 5
15 Mast height, lowered (2-stage std. mast) in. (mm) 85.4 (2,170) 85.4 (2,170) 85.4 (2,170)
16 Mast height, extended (2-stage std. mast)† in. (mm) 176 (4,470) 176 (4,470) 176 (4,470)
17 Maximum fork height (2-stage std. mast)** in. (mm) 128 (3,250) 128 (3,250) 128 (3,250)
18 Free lift height (2-stage std. mast) in. (mm) 5.5 (140) 5.5 (140) 5.5 (140)
19 Height overhead guard in. (mm) 83.1 (2,110) 83.1 (2,110) 83.1 (2,110)
20 Length, with standard forks in. (mm) 141.5 (3,595) 141.5 (3,595) 141.5 (3,595)
21 Length to fork face (2-stage mast) in. (mm) 99.4 (2,525) 99.4 (2,525) 99.4 (2,525)
22 Overall width, at drive tires (single) in. (mm) 45.3 (1,150) 45.3 (1,150) 45.3 (1,150)
23 Forks, thickness x width x length in. (mm)
1.6 x 3.9 x 42
(40 x 100 x 1,070)
1.6 x 3.9 x 42
(40 x 100 x 1,070)
1.6 x 3.9 x 42
(40 x 100 x 1,070)
24 Carriage width / ITA Class in. (mm) 40.9 (1,040) / II 40.9 (1,040) / II 40.9 (1,040) / II
25 Ground clearance, under mast in. (mm) 5.5 (140) 5.5 (140) 5.5 (140)
26 Ground clearance, center of wheelbase in. (mm) 6.2 (158) 6.2 (158) 6.2 (158)
27 Right angle stacking aisle (2-stage mast)†† in. (mm) 104.1 (2,645) 104.1 (2,645) 104.1 (2,645)
28 Turning radius, outside in. (mm) 86.2 (2,190) 86.2 (2,190) 86.2 (2,190)
PERFORMANCE
29 Travel speed, forward, loaded / unloaded mph (km/h) 11.2 (18) / 11.8 (19) 11.2 (18) / 11.8 (19) 11.5 (18.5) / 11.8 (19)
30 Lifting speed, loaded / unloaded (2-stage mast) fpm (mm/s) 120 (610) / 124 (630) 120 (610) / 124 (630) 124 (630) / 130 (660)
31 Lowering speed, loaded / unloaded (2-stage mast) fpm (mm/s) 98 (500) / 98 (500) 98 (500) / 98 (500) 98 (500) / 98 (500)
32 Maximum drawbar pull, loaded lbs. (kN) 3,960 (17.6) 4,720 (21) 4,072 (18.1)
33 Maximum gradability % 32 40 36
34 Service brake, operation / control Foot / Hydraulic Foot / Hydraulic Foot / Hydraulic
35 Parking brake, operation / control Hand / Mechanical Hand / Mechanical Hand / Mechanical
36 Steering, type FHPS FHPS FHPS
DRIVE
37 Engine Manufacturer / Engine model Nissan / K21 Nissan / K25 Yanmar / 4D94LE
38 Rated output (SAE Gross) HP (kW) @ rpm 56 (41) @ 2,700 60 (44) @ 2,700 65 (48) @ 2,450
39 Maximum torque (SAE Gross) lb. - ft. (Nm) @ rpm 119 (160) @ 1,600 142 (193) @ 1,600 141 (191) @ 1,800
40 No. of cylinders / displacement cu. in. (cm3) 4 / 126 (2,065) 4 / 152 (2,488) 4 / 187 (3,062)
41 Fuel tank capacity U.S. gallons (liters) 15.3 (58) 15.3 (58) 15.3 (58)
OTHER
42 Relief pressure, maximum psi (bar) 2,650 (181) 2,650 (181) 2,650 (181)
43 Transmission Powershift Powershift Powershift
44 Sound level, at operator ears dB 82 83 -
NOTE: Most values shown in this publication are rounded. Therefore, direct conversion between metric and English or Imperial may be slightly different from those
shown. The performance of machines is affected by the condition of the truck and how it is equipped, as well as the nature and condition of the operating area.
If these specifi cations are critical or if your needs exceed the specifi cations shown here, discuss the proposed application with your authorized dealer.
*Optional masts, attachments, longer load dimensions, and higher lifting heights may result in downrating of the capacity. Contact your authorized dealer.
**Other mast heights available. See MAST DATA chart for other standard mast heights. Contact your authorized dealer.
†Includes 48-inch (1,220 mm) high load backrest. Contact your authorized dealer.
††Add load distance and clearance. Contact your authorized dealer.
