9 Appendix Leica DISTO™ A5 1.3.0 gb
D
GB
F
I
E
P
NL
DK
S
N
FIN
J
CN
RC
ROK
PL
H
RUS
CZ
* maximum deviation occurs under unfavourable conditions
such as bright sunlight or when measuring to poorly
reflecting or very rough surfaces. For distances over 30 m the
maximum deviation may increase to a maximum of ± 10 mm.
Measuring Conditions
Measuring Range
At night, at dusk and when the target is shadowed
the measuring range without target plate is
increased.
Use a target plate to increase the measurement
range during daylight or if the target has a bad reflec-
tion.
Measuring Surfaces
Measuring errors can occur when measuring toward
colourless liquids (e.g. water) or dust free glass,
styrofoam or similar semi-permeable surfaces.
Aiming at high gloss surfaces deflects the laser beam
and measurement errors can occur.
Against non-reflective and dark surfaces the measu-
ring time can be increased.
Care
Do not immerse the unit in water. Wipe off dirt with
a damp, soft cloth. Do not use aggressive cleaning
agents or solutions. Treat the optical surfaces with
the same care that you would apply to eyeglasses
and cameras.
Integrated telescopic
viewer
2x magnification
Display illumination 9
Integrated level 9
Multifunctional
endpiece
9
Timer 9
Single Measurement 9
Maximum, Minimum,
Continuous Measure-
ment
9
Historical storage of 20 values
Indirect Measuring
functions with Pytha-
goras
9
Storage of constant 9
Area/Volume calculation
with room calculations
9
Addition/Subtraction 9
Tripod thread 9
Battery life,
Type AA, 2 x 1.5V up to 10 000
measurements
IP rating IP 54
splash proof, dust proof
Dimension 148 x 64 x 36 mm
Weight (with batteries) 241 g
Temperature range:
Storage
Operating
-25°C to +70°C
(-13°F to +158°F)
-10°C to +50°C
(-14°F to +122°F)
